Lab Microscope Accessories 4X 10X 20X 40X 60X 100X Achromatic Objective Lens 195 mm Conjugate Distance Tube Length 160 mm for Biological Microscope Objective(100X)
$55.12
- Type: Microscope achromatic Objective lens.
- Magnification: 4X/10X/20X(S)/40X(S)/60X(S)/100X(S+Oil).
- Mounting size: 20.2 mm; Standard RMS thread; Material: Precision Copper core; Tube length: 160 mm.
- Our microscope accessories are made of high-quality materials to ensure durability and stability for long-term use.
- We have a wide range of microscopes, microscope cameras, microscope slides, microscope eyepiece lens, accessories and other related products.
This product is fulfilled by seller
Specification:
Type: Microscope achromatic Objective lens
Magnification: 4X/10X/20X(S)/40X(S)/60X(S)/100X(S+Oil)
Mounting size: 20.2 mm
Standard RMS thread
Material: Precision Copper core
Tube length: 160 mm
standard thickness of cover glass 0.1 7mm
Conjugate Distance: 195 mm
Mounting Thread: 20.3 x 0.705 mm
Standard DIN 160/0.17 HD achromatic objectives
for Biological microscope
4X: Numerical Aperture (NA) 0.1; working distance 18 mm
10X: Numerical Aperture (NA) 0.25; working distance 7 mm
20X (S): Numerical Aperture (NA) 0.4; working distance 0.55 mm
40X(S): Numerical Aperture (NA) 0.65; working distance 0.53 mm
60X (S): Numerical Aperture (NA) 0.65; working distance 0.13 mm
100X (S+Oil): Numerical Aperture (NA) 1.25; working distance 0.1 3mm
If there are any issues with the microscope Accessories upon arrival, simply inform us, and we will assist in resolving the matter promptly.
Type: Microscope achromatic Objective lens
Magnification: 4X/10X/20X(S)/40X(S)/60X(S)/100X(S+Oil)
Mounting size: 20.2 mm
Standard RMS thread
Material: Precision Copper core
Tube length: 160 mm
standard thickness of cover glass 0.1 7mm
Conjugate Distance: 195 mm
Mounting Thread: 20.3 x 0.705 mm
Standard DIN 160/0.17 HD achromatic objectives
for Biological microscope
4X: Numerical Aperture (NA) 0.1; working distance 18 mm
10X: Numerical Aperture (NA) 0.25; working distance 7 mm
20X (S): Numerical Aperture (NA) 0.4; working distance 0.55 mm
40X(S): Numerical Aperture (NA) 0.65; working distance 0.53 mm
60X (S): Numerical Aperture (NA) 0.65; working distance 0.13 mm
100X (S+Oil): Numerical Aperture (NA) 1.25; working distance 0.1 3mm
If there are any issues with the microscope Accessories upon arrival, simply inform us, and we will assist in resolving the matter promptly.
| Brand Name | Generic |
|---|---|
| Part Number | IHFEFCFFF-100X |
