Optima Royal Urinal Flush Valve

Exposed, Water Saver (1.5 gpf/5.7 Lpf), Sensor Operated Royal(R) Model Urinal Flushometer, for 3/4" top spud urinals. Quiet, Exposed, Diaphragm Type, Chrome Plated Urinal Flushometer for either left or right hand supply. Features: Water Saver (1.5 gpf/5.7 Lpf) PERMEX(tm) Synthetic Rubber Diaphragm with Dual Filtered Fixed Bypass OPTIMA(R) EL-1500 Self-Adaptive Infrared Sensor with Indicator Light Non-Hold-Open Integral Solenoid Operator Chrome Plated Wall Cover Plate (for 2-gang Electrical Box) with Vandal Resistant Screws 3/4" I.P.S. Screwdriver Bak-Chek(tm) Angle Stop Free Spinning Vandal Resistant Stop Cap Adjustable Tailpiece High Back Pressure Vacuum Breaker Flush Connection with One-Piece Bottom Hex Coupling Nut, Spud Coupling and Flange for 3/4" Top Spud Sweat Solder Adapter with Cover Tube and Cast Set Screw Wall Flange High Copper, Low Zinc Brass Castings for Dezincification Resistance Non-Hold-Open Integral Solenoid Operator, Fixed Metering Bypass and No External Volume Adjustment to Ensure Water Conservation Flush Accuracy Controlled by CID(tm) Technology Diaphragm, Stop Seat and Vacuum Breaker to be molded from PERMEX(tm) Rubber Compound for Chloramine Resistance Valve Body, Cover, Tailpiece and Control Stop shall be in conformance with ASTM Alloy Classification for Semi-Red Brass. Valve shall be in compliance with the applicable sections of ASSE 1037, ANSI/ASME A112.19.6 and Military Specification V-29193. Installation conforms to ADA requirements. Automatic: Sloan OPTIMA(R) equipped Flushometers provide the ultimate in sanitary protection and automatic operation. There are no handles to trip or buttons to push. The Flushometer operates by means of an infrared sensor that adapts to its surrounding. Once the user enters the sensor's effective range and then steps away, the Flushometer Solenoid initiates the flushing cycle to flush the fixture. Hygienic: User makes no physical contact with the Flushometer surface
