Gebildet 4 Pieces 40/30 Amp Waterproof Relay Switch Harness Set - 12V DC 5-Pin SPDT Automotive Relays 12 AWG Hot Wires
$0.00
- 12 V DC automotive waterproof relay (max 14 V). Note: 12 V and 14 V are coil voltages, they are not the voltage that triggers the switch
- Wire Specifications: Black - Ground (85), Red - VDC (30), White - Trigger (86), Yellow - Output N/C (87a), and Blue - Output N/O (87)
- Excellent waterproof performance, high quality in any weather conditions
- Pre-wired Harness - Heavy duty 12 AWG wiring harness. Black.
- Easy Wiring - The relay sockets come with color-labeled wires for loads/accessories convenient wiring. Metal mounting tab on the relay for easy installation
This product is fulfilled by seller
Package Content:
4 x 5-Pin SPDT Relay and harness
Specifications:
Coil Voltage: 12V DC
Coil Current: 160 mA
Switching Voltage: 14V DC Max
Contact Current Rating:
- NO 40A 14V DC
- NC 30A 14V DC
Ambient Temperature: -40 ~ +125 degree C (no condensation)
Initial contact resistance (at 6VDC 1A): 50mΩ¸ Max.
Initial insulation resistance: 100MΩ¸ Min. (DC500V)
Initial dielectric strength:
- Between open contacts: AC500V, 50/60 Hz 1Min.
- Between coil and contact: AC500V, 50/60 Hz 1Min.
Endurance (operations):
- Mechanical (at 7,200 ops./h): 10,000,000
- Electrical (at 600 ops./h): 100,000
Please Note:
--- Easy to mount - No instructions were included - You do need to know a little about electrical.
--- For your and others' safety, let professional technicians to install the equipment.
4 x 5-Pin SPDT Relay and harness
Specifications:
Coil Voltage: 12V DC
Coil Current: 160 mA
Switching Voltage: 14V DC Max
Contact Current Rating:
- NO 40A 14V DC
- NC 30A 14V DC
Ambient Temperature: -40 ~ +125 degree C (no condensation)
Initial contact resistance (at 6VDC 1A): 50mΩ¸ Max.
Initial insulation resistance: 100MΩ¸ Min. (DC500V)
Initial dielectric strength:
- Between open contacts: AC500V, 50/60 Hz 1Min.
- Between coil and contact: AC500V, 50/60 Hz 1Min.
Endurance (operations):
- Mechanical (at 7,200 ops./h): 10,000,000
- Electrical (at 600 ops./h): 100,000
Please Note:
--- Easy to mount - No instructions were included - You do need to know a little about electrical.
--- For your and others' safety, let professional technicians to install the equipment.
| Brand Name | Gebildet |
|---|---|
| Part Number | E1408 |
