10T Hydraulic Cylinder Jack Portable Hydraulic Jack Hydraulic Lifting Cylinders Kit Hydraulic Ram Jack with Hand Pump for Mechanical Equipment Installation RSC-1050 CP-180 (10T)
- Strong and Durable: The hydraulic cylinder jack is made of high-class steel with a plastic spraying treatment, making it impact-resistant, wear-resistant, and not easy to deform, ensuring a long service life
- Strong Lifting Force: The mechanism boasts a substantial lifting capacity of 22046 lbs, which enables it to lift heavy objects of significant weight with ease, fulfilling various lifting requirements
- Thoughtful Design: It can be used in narrower and lower spaces and has a stroke of 2 inches to meet your usage needs. In addition, the large o-il storage capacity makes it can be used for a long time
- Simple Operation: You can tighten the return switch on the hydraulic pump clockwise, press the handle and the jack automatically jacks up. After loosening the return switch, the jack automatically retracts
- Time and Energy Saving: With the hydraulic ram jack, you can lift heavy objects more easily, reducing the risk of manual labor, improving the safety of use, and enhancing efficiency
Specification
Cylinder Model: RSC-1050
Hand Pump Model: CP-180
Color: Green
Shape: Cylinder
Material: Steel
Process: Plastic Spraying
Interface Size: 3/8''
Maximum Output Pressure:700/10000KG/CM2
Output Pressure: High Pressure 60KG/CM2
Length of O-il Pipe: 1m/3.28ft
Total Tonnage: 10T/22046lbs
Stroke: 50mm/2in
Travel: 50min
Collapsed Height: 102mm/4.02in
Extended Height: 152mm/5.98in
Cylinder Jack Size(D*H): 6.4*10.4cm/2.52*4.09inch
Hand Pump Size: 34*10*14cm/13.39*3.94*5.51inch
Package Size: 37.5*22.5*16.5cm/14.76*8.86*6.5inch
Gross Weight: 5.5kg/12.13lbs
Net Weight: 5kg/11.02lbs
Package Included
1* Hydraulic Cylinder Jack
1* Hand Pump
Notes
1.Please use the product on a flat surface, not on soft or rough ground, and do not apply unilateral force to the spindle.
2.Before use, the interface between the jack and the pump should be installed firmly, otherwise it will leak o-il. A slight o-il leak at the interface is normal.
3.The first time you use it, you need to press the hydraulic pump a few more times to remove the air inside the jack.
4.Please allow the slight color difference caused by the shooting light and 1-3 cm error due to manual measurement, and make sure you do not mind before ordering.
| Brand Name | WsrrLun |
|---|---|
| Part Number | RSC-1050 RSC-2050 RSC-3050 CP-180 CP-700 |
| Load Capacity | 10 |
