Passive Double Balanced Mixer, HMC213 Passive Mixer Diode Frequency Conversion Module
$0.00
- EXQUISITE QUALITY - Made of exquisite quality aluminum alloy casing, sturdy and long-lasting to use
- PASSIVE DOUBLE-Balanced Mixer - It can be used as up-converter, down-converter, two-phase modulator and demodulator or phase comparator.
- LIGHT WEIGHT - The passive mixers adopt mini components design,compact and light weight
- EASY TO USE - Passive mixers use GaAs Schottky diodes and novel planar transformer on-chip balun structures.
- LOW CONVERSION LOSS - Passive Mixer has low conversion loss of 8.5dB
This product is fulfilled by seller
Features:
Passive double-balanced mixer, 8-pin surface-mount plastic package (MsOP).
Passive mixers use GaAs Schottky diodes and novel planar transformer on-chip balun structures. It can be used as up-converter, down-converter, two-phase modulator and demodulator or phase comparator. The mixer has the advantage of high isolation The passive mixers adopt mini components design,compact and light weight Passive Mixer has low conversion loss of 8.5dB
Specification:
Shell material: aluminum alloy
Model: HMC213 module
Conversion loss: 8.5db
LO to isolation: 40dB
LO to IF isolation: 35dB
Frequency range, and LO: 1.5-4.5G
Frequency range, IF: DC-1.5G
1dB gain compression (input) : 8dBm
IP3 (input) : 18dBm
Weight: Approx.46g/1.7oz
Package list:
1 x Passive Mixer
Passive double-balanced mixer, 8-pin surface-mount plastic package (MsOP).
Passive mixers use GaAs Schottky diodes and novel planar transformer on-chip balun structures. It can be used as up-converter, down-converter, two-phase modulator and demodulator or phase comparator. The mixer has the advantage of high isolation The passive mixers adopt mini components design,compact and light weight Passive Mixer has low conversion loss of 8.5dB
Specification:
Shell material: aluminum alloy
Model: HMC213 module
Conversion loss: 8.5db
LO to isolation: 40dB
LO to IF isolation: 35dB
Frequency range, and LO: 1.5-4.5G
Frequency range, IF: DC-1.5G
1dB gain compression (input) : 8dBm
IP3 (input) : 18dBm
Weight: Approx.46g/1.7oz
Package list:
1 x Passive Mixer
