MACHINIST LGA 1150 Motherboard, H81 Micro ATX Intel 4th Gen Gaming Motherboard for Desktop PC Support 1333/1600MHz DDR3 Dual Channel Max 16G, i3 i5 i7/Xeon E3 V3 Processor, NGFF M.2, SATA 3 H81M-PRO
$89.99
- Intel LGA 1150 socket: The Micro ATX motherboard is powered by the H81 chipset and supports Intel 4th generation Core i3/i5/i7, Xeon E3/V3 series, Celeron G series and Pentium G series processors. (Eg. Core i7-4790K, Core i7-4770, Core i5-4670, Core i5-4590, Core i3-4170, Xeon E3-1285 v3, Pentium G3470, Celeron G1830, etc.)
- Dual-channel DDR3 memory slots: 2 DDR3 non-ECC desktop memory slots, unbuffered, support effective frequencies of 1280/1333/1600/1866MHz, and a maximum capacity of 16GB
- High performance interface: Support Gigabit Ethernet interface, compatible with VGA+HDMI dual output high-definition display interface. PCIe 2.0 protocol standard, X16 channel bandwidth can reach 8GB/s. NVME M.2 Slot, Realtek ALC662 audio chip, 4-channel sound card, brings you a different ultimate experience
- The package includes: 1*SATA cable, 1*I/O baffle, 1*motherboard. The CR2032 battery on the motherboard has been removed. It is not included in the package. Please purchase it yourself. And the user manual is not included in the package. You can download the manual file on the product details page. If you don't know where to download the driver, it is recommended to use the win 10 system
- Note: The SATA 3.0 interface and M.2 interface in this ddr3 motherboard are incompatible. If you need to use a SATA M.2 hard drive, then the two SATA 3.0 ports will not be available. If you want to use the SATA 3.0 interface, the M.2 interface will not be available. If you need to use the SATA 3.0 interface, you need to pull out the 4 black small parts on the right end of the M.2 slot and insert them into the right slot. If you need to use the M.2 slots, you don't need to move them
- Note: If you need the motherboard to enter the BIOS, please press the "Del" key continuously after pressing the startup key. Please do not wait until the startup LOGO screen appears on the computer screen before operating, because it is already too late
- Tip1: Before purchasing this computer motherboards, make sure you can install it yourself. After the motherboard is installed normally, if there is no display, no boot, no picture, no network card, no sound card, etc. It is recommended that customers restore factory settings, reset CMOS, or use an eraser to erase the metal pins on the memory, CPU, or graphics card
- Tip2: The CPUs of the Intel Xeon E3 V3 series are server CPUs, and most of them do not have integrated graphics. Generally, only the CPU models with the suffix "5" have integrated graphics. For example: E3-1245 v3, E3-1275 v3, E3-1285 v3, E3-1275L v3, E3-1225 v3 and other CPUs support integrated graphics. While Intel Core i3, i5 and i7 series processors almost all support integrated display, only the CPU model with the suffix "F" letter has no integrated display function, which is "ix-xxxxF"
This product is fulfilled by seller
The all-solid capacitor LGA 1150 motherboard, equipped with NGFF M.2 interface and 8pin DC interface, gives you a high-end gaming and office experience.
Specification:
Brand: MACHINIST
Model: H81M-PRO S1
Chipset: H81
Condition: Full new
CPU socket: LGA 1150
Structure: Micro-ATX
Memory socket: 2*DDR3
Max memory supported: 2*8G DDR3
Memory type supported:Only supports DDR3 Non ECC memory.(Please use internationally renowned brand memory.)
Integrated video card: yes(Requires processor to support integrated display).
Motherboard dimension:
Motherboard weight(including package): 0.7kg or so
Note:
(1) The color of the bottom plate of the slot may vary from batch to batch, but it will not affect the use of the product. The product is constantly optimized and upgraded.
(2) Please allow 1-3mm differs due to manual measurement.
(3) Due to the different display and different light, the picture may not show the actual color of the item. Thanks for your understanding.
(4) This planform needs powerful power supply. please make sure your power supply can enough to supports this planform.(at least 500w brand power supply)
Specification:
Brand: MACHINIST
Model: H81M-PRO S1
Chipset: H81
Condition: Full new
CPU socket: LGA 1150
Structure: Micro-ATX
Memory socket: 2*DDR3
Max memory supported: 2*8G DDR3
Memory type supported:Only supports DDR3 Non ECC memory.(Please use internationally renowned brand memory.)
Integrated video card: yes(Requires processor to support integrated display).
Motherboard dimension:
Motherboard weight(including package): 0.7kg or so
Note:
(1) The color of the bottom plate of the slot may vary from batch to batch, but it will not affect the use of the product. The product is constantly optimized and upgraded.
(2) Please allow 1-3mm differs due to manual measurement.
(3) Due to the different display and different light, the picture may not show the actual color of the item. Thanks for your understanding.
(4) This planform needs powerful power supply. please make sure your power supply can enough to supports this planform.(at least 500w brand power supply)
| Brand Name | MACHINIST |
|---|---|
| Part Number | H81 |
| Compatible Processors |
|
| Memory Storage Capacity Unit | GB |
| Memory Storage Capacity | 32.000000 |
| Memory Clock Speed | 1833.000000 |
| Memory Clock Speed Unit | MHz |
| RAM Memory Maximum Size Unit | GB |
| RAM Memory Maximum Size | 32.000000 |
| CPU Model | Pentium |
| Total PCIe Ports | 2 |
| Item Height Unit | Inches |
| Item Height base to top | 8.660000 |
| Item Length Unit | Inches |
| Item Length Longer Edge | 6.690000 |
| Item Width Unit | Inches |
| Item Width Shorter Edge | 1.570000 |
| Number of Batteries | 1 |
