M3-M16 Universal Electric Tapping Machine 375RPM Electric Tapping Arm 1000mm Flexible Tapping Arm Included 8pcs Standard Collets, For Tapping Steel, Iron, Copper, Aluminum
$0.00
- 【INTELLIGIENT TAPPING ARM】HD human-machine interface,adjustable speed.Imported servo motor with strong output force.Enhanced reducer with durabl gears.Intelligent control syste stable and reliable program.Safety torque collet,overload protection device
- 【PARAMETERS】Tapping Capacity: M3 to M16; Working Direction: Vertical, universal; Working Radius: Horizontal 1200mm and Vertical 400mm; Rotation Speed:0-375r/min
- 【PRECISE HOLES ALIGNMENT】Triple balanced articulated arm made entirely of aluminum, which guarantees a fast and precise holes alignment.Variation of the speed of rotation according to diameter of tapping and counterclockwise maximum speed for fast tool output
- 【AUTO-BLOW OILING FUNCTION】Automatic fuel injection and blowing assist ,imported servo motor strong output, Tapping oil to increase lubrication, Powerful air nozzle cleaning
- 【APPLICABLE MATERIAL】alumimum, copper, steel, cast iron, Q235, S136, mold steel, 718H, 40Cr, stainless steel and other metal materials
This product is fulfilled by seller
600W Electric Tapping Machine 360° Universal Tapping Arm with advanced professional arm design, can be positioned in many ways, quick, accurate and convenient positioning; Electric Tapping & Drilling Threading Machine is multi-purpose, suitable for tapping steel, aluminum, plastic and wood etc.
Specification
Motor power: 600W
Tapping direction: Vertical, Universal
Working radius: 1100MM
Control method: touch screen
Speed: 0-375 rpm
Chuck specifications: M3-M16
Weight: 30KG
Features
- Upgrade Auto-blow Oiling Function.
- Magnet positioning for rapid alignment of the spindle.
- Rotational head which allows threading in any position.
- Safety Torque Collet, Overload Protection Device.
- Minimum noise and low electricity consumption.
- Possibility of tapping blind and open holes thanks to the adjustable clutch.
- HD Human-Machine Interface, Adjustable Forawrd and Backward Speed.
- Triple balanced articulated arm made entirely of aluminum, which have a fast and precise holes alignment.
- Variation of the speed of rotation according to diameter of tapping and counterclockwise maximum speed for fast tool output.
- The machine can do the following work like internal tapping, outer circular die, chamfer of inner hole, self-tapping braces.
Packing list:
1*automatic tapping machine
If you have any questions, please feel fr-ee to send us an email. We will reply you within 24 hours. We are honored to provide you with satisfactory service.
Specification
Motor power: 600W
Tapping direction: Vertical, Universal
Working radius: 1100MM
Control method: touch screen
Speed: 0-375 rpm
Chuck specifications: M3-M16
Weight: 30KG
Features
- Upgrade Auto-blow Oiling Function.
- Magnet positioning for rapid alignment of the spindle.
- Rotational head which allows threading in any position.
- Safety Torque Collet, Overload Protection Device.
- Minimum noise and low electricity consumption.
- Possibility of tapping blind and open holes thanks to the adjustable clutch.
- HD Human-Machine Interface, Adjustable Forawrd and Backward Speed.
- Triple balanced articulated arm made entirely of aluminum, which have a fast and precise holes alignment.
- Variation of the speed of rotation according to diameter of tapping and counterclockwise maximum speed for fast tool output.
- The machine can do the following work like internal tapping, outer circular die, chamfer of inner hole, self-tapping braces.
Packing list:
1*automatic tapping machine
If you have any questions, please feel fr-ee to send us an email. We will reply you within 24 hours. We are honored to provide you with satisfactory service.
| Brand Name | CYMYYDS |
|---|---|
| Part Number | 75008891 |
