Zhpuostd Digital HDMI Extender 1080P&60HZ, Working Distance up 20Km，EDID RS232 HDCP,BI-DI Audio Transmission，HDMI Extension Over Fiber Optic
- ???? ????????? ????????：The HDMI Extender has a maximum data rate of 6.75Gbps and a maximum pixel clock of 165MHz.
- ??-?? ???????????：One fiber transmits and receives signals in both directions at the same time, saving fiber resources.
- ??????? ????? ????????????: HDMI fiber expander supports serial RS232 signals for remote control of RS232 devices.
- ?????-?? ??? ?????????? ??????: Strengthens the electrostatic surge protection capability of the HDMI interface, making the use more stable.
- ???????????? ????????????: Support video resolution max up to 1080p@60Hz，no delay and no loss, audio and video synchronous transmission.
Overview：
The Zhpuostd HDMI Fiber expander provides HDMI and long range expansion through a single fiber, it supports high resolution up to 1920*1200@60Hz, and supports reverse RS232 and BIDI bidirectional transmission. The extender has good stability and strong security, and can be widely used in long-distance transmission requiring high resolution and high quality. Is your choice.
Features：
Uncompressed transmission, no delay, no losses
Optical fiber transmission HDMI, audio and RS232 signals, transmission distance of upto 20km
Highest video resolution 1080p@60Hz
Comply with HDMI 1.4 standard
High compatibility, can automatically match the source and display device, easy touse
Built-in ESD protection system, more stable signal
Simple installation, plug and play
specification：
HDMI Cable Range:<5M( Resolution: 1920*1200@60Hz)
Optical fiber Wavelength: Single-mode 1310/1550nm or Multi-mode850nm
Transmission distance:300m/20km
Power supply:The power adapter: DC 5~12V
Power dissipation: MAX 6W
Temperature Operating: -5℃ ~ +70℃
Humidity Operating: 5% ~ 90%
Audio Support:Dolby TrueHD, Dolby Digital Plus, DTS, DTS-ES 6.1, DTSHD,DTS-HD-HRA, DTS-HD Master, (PCM-2CH)
Dimension (WxDxH):3.66 x 2.28x 0.9in (94x58x23mm)
Weight:50g/ 0.11lb
Casing：Aluminum Casing
Whats in it？
HDMI optical fiber transmitter——1 pcs
HDMI optical fiber receiver——1 pcs
Fiber optic module——1 set
Power adapter——2 pcs
User manual——1 pcs
| Brand Name | Zhpuostd |
|---|---|
| Part Number | 00001 |
