Steloproad Mini 4K DVI Fiber Extender - DVI to Fiber Converter UHD 4Kx2K DVI Video Optical Transceiver Up to 20km Over Single-Mode Fiber with Backward RS232

Overview:

The Mini-Type DVI Fiber optic extender provides extension of DVI signals and RS232 via single fiber optic cable, high resolution up to 4k*2k@60Hz, which can be used for a wide range of applications requiring long distance stable transmission of high resolution real time video. The device has the ability of anti-interference to ensure the stability of the signal, is ideal for large-screen display, conferencing systems and home entertainment and so on.

Features:

• Transmits DVI video signals and RS232 up to 20km over a single fiber optic cable
• Uncompressed transmission, no delay, no losses
• Support serial RS232 signal transmission
• Support video resolution up to 4k*2k@60Hz, YUV 4:2:0
• Hot-Pluggable, EMI/RFI Resistant
• Compliance with DVI 1.0 and HDCP 1.2 standard
• High compatibility, can auto-match source and display device
• Support EDID, DDC and HPDT signal

Specifications:

• RS232: 3 Pin terminal, Baud rate ≤ 38400
• Power Input: 5V DC, USB Type-C
• Bandwidth: 10.2Gbps
• Transmission Distance: Up to 20km (Over Single-mode Fiber)
• Power Dissipation: <5W
• Signal Support: DVI1.0 format standard and HDCP compliant
• Video Support: Up to 720P/960P/1080p@60Hz, 4K*2K@60Hz
• Chroma Subsampling: Max 3840*2160@60Hz (4:2:0)
• Max 3840*2160@30Hz (4:4:4, 4:2:2)
• EDID: Bi-Directional (Forward + Backward) Transmission: Support Dynamic EDID, Plug & Play, no need to learn
• Single-Directional (Forward) Transmission: Support EDID learning manually
• Dimensions (LxWxH): 2.87 x 1.73 x 0.69in (73x44x17mm)
• Weight: 60g / 0.13lb
