IDC Socket CHENJIN 20PCS 2x5 FC-10P 2.54mm Dual Rows IDC Sockets Female Connector for Flat Ribbon Cable
$0.00
- 10-pin standard 0.1inch (2.54mm) socket with 0.1inch (2.54mm) pitch connectors.
- It mates with standard 0.1inch (2.54mm) PCB pin headers or male IDC connectors.
- Insulation displacement (IDC) contacts allow them to be quickly and easily crimped onto flat ribbon cables.
- Easy to use: Just put the flat cable and IDC connector that needs to be crimped into the crimping device for crimping, so that the insulation at the crimp is always facing the wire. Do not pull them apart when crimping.
- Package Contents: 20PCS 2 x 5pin 10 Pin Double Row IDC Female Socket Connector.
This product is fulfilled by seller
Specification:
Model: 2.54IDC-10P
Number of rows: 2
Needles/digit: 10
Connector Type: IDC Female Thread
Pitch: 2.54mm/0.1inch
Overall Dimensions: 17 x 17 x 6mm/0.67 x 0.67 x 0.24 inch (Lx WxH)
Colour: Black
Material: high quality phosphor bronze raw material
Insulation material: PVC
Contact Material: Brass
Rated current: 3A
Operating temperature: -40 degrees Celsius to +105 degrees Celsius
Contact Resistance: 20m ohms max at DC 100mA
Insulation Resistance: 1000M ohm minimum at 500V DC
Withstand voltage: AC 1000V
Package Contents: 20PCS 10P IDC Socket Connector
Notice:
1) Different monitors may have different colors, please understand.
2) Please allow 1-2mm error due to manual measurement, please make sure you don't mind your bid.
Model: 2.54IDC-10P
Number of rows: 2
Needles/digit: 10
Connector Type: IDC Female Thread
Pitch: 2.54mm/0.1inch
Overall Dimensions: 17 x 17 x 6mm/0.67 x 0.67 x 0.24 inch (Lx WxH)
Colour: Black
Material: high quality phosphor bronze raw material
Insulation material: PVC
Contact Material: Brass
Rated current: 3A
Operating temperature: -40 degrees Celsius to +105 degrees Celsius
Contact Resistance: 20m ohms max at DC 100mA
Insulation Resistance: 1000M ohm minimum at 500V DC
Withstand voltage: AC 1000V
Package Contents: 20PCS 10P IDC Socket Connector
Notice:
1) Different monitors may have different colors, please understand.
2) Please allow 1-2mm error due to manual measurement, please make sure you don't mind your bid.
| Brand Name | CHENJIN |
|---|---|
| Part Number | IDCSDRSC-17x17x6-B20 |
| Maximum Voltage Unit | Volts |
| Maximum Voltage | 1000.000000 |
| Item Height Unit | Inches |
| Item Height base to top | 0.670000 |
| Item Length Unit | Inches |
| Item Length Longer Edge | 0.670000 |
| Item Width Unit | Inches |
| Item Width Shorter Edge | 0.240000 |
