PF10000288741
In stock
Easy-Tap Insulation Piercing Connector - IPCS Series, 2/0-4 AWG Main and 10-14 AWG tag Conductor Range, 1.8" Width, 3" Height, 2.2" Length
$93.36
- Insulation-piercing connector for tapping electrical lines
- Can be used on main lines from 2/0 to #4 AWG with tap lines from #10 to #14 AWG
- Can be used in copper-to-copper, copper-to-aluminum, and aluminum-to-aluminum solid or stranded wire applications
- Rated for 600V and 90 degrees C
- Meets ANSI C119.4 requirements and is UL 486B Listed
This product is fulfilled by seller
| Brand Name | NSI |
|---|---|
| Part Number | IPCS2001* |
| Voltage Unit | Volts |
| Gauge Decimal Value | 10.000000 |
| Gauge String Value | 10 |
| Maximum Voltage Unit | Volts |
| Maximum Voltage | 600.000000 |
| Operating Voltage Unit | Volts |
| Operating Voltage | 600.000000 |
| Item Height Unit | Inches |
| Item Height base to top | 3.000000 |
| Item Length Unit | Inches |
| Item Length Longer Edge | 2.200000 |
| Item Width Unit | Inches |
| Item Width Shorter Edge | 1.800000 |
| California Proposition 65 Warning Type | Chemical |
