JUXINICE DB9 Connector to Bare Wire END 10ft D-SUB 9 pin RS232 Serial Extension Cable Double Shielded, DB9 Male to 9-Core Wires - Black
- DB9 connector to bare wire end cable 10ft: Extend Serial Cable with adopts 26awg tinned copper core, aluminum foil shield and metal braided screen to effectively prevent external signal interference.
- Multiple communication protocols：DB9 cable Straight-through wiring (i.e. pin 1 to pin 1) design per industry standards, Supports RS232/RS485/RS422 and other communication protocols. Usually: (RS232 connected to 235pin) (RS485 connected to 38 or 12 pin)
- 9 Wires Core color : 1-black, 2-brown, 3-red, 4-orange, 5-yellow, 6-green, 7-blue, 8-gray, 9-white
- Widely Applications:The DB9 to bare wire can be used for automatic control equipment, Server, CNC, Electrical equipment, UPS, PLC, servo driver, communication instrument, electronic scale, medical equipment etc.
- Durable: db9 bare wire adopts black PVC molded and injection molded shell, which eliminates heavy load strain and makes it strong and reliable.
DB9 serial connector adopts gold-plated connector, with fine solder joints, pluggable resistance and good contact to ensure high quality, durability and long service life. Effectively reduce the attenuation value, and the signal transmission is more efficient and stable
service life. Effectively reduce the attenuation value, and the signal transmission is more efficient and stable
Technical specifications:
Name: DB9 connector plug type: male
Connector material: punching pin gold-plated 3U male and female contact material: Copper
Shell material: environmental protection PP engineering material
Cable sheath: PVC
Shielding composition: wrapped aluminum foil + 96# metal woven mesh
Cable length: 3m / 10ft
Wire gauge: 26AWG
Package includes:
1×10FT DB9 male cable
| Brand Name | JUXINICE |
|---|---|
| Part Number | JUXIN |
| Gauge Decimal Value | 26.000000 |
| Cable Length Decimal Value | 3.000000 |
| Cable Length String Value | 3 |
| Cable Length Unit | Feet |
