5/8” Heim Joints Rod End Kit,.625" Chromoly Heim Joints Panhard Rod End Kit for Steering,Suspension, Traction Bars, Right&Left Hand Thread with Tube Adapters & Jam Nuts - 2Set
$54.99
- 5/8" Rod end heim joint kit:5/8" left & right hand thread heim joint set with jam nut,tube adapters for .790" id tube
- Premium quality:The 5/8" heim joint rod end kit are heat treated and hard chrome plated finish to provide a longer use and heavy duty performance(load capacity- 17955 lbs)
- Easy to install: Our heim joints for 5/8” rod end can be MiG and TIG welded with additional hardware for mating installation
- Widely use:The 0.625" rod end heim joint kit great for steering and suspension,traction bars, sand rails,a-arms,race car ,rock crawlers,steering joints and links joints on hot rods
- The heim joint rod ends is with 5/8” shaft with 18tpi. 5/8” bore hold is the strongest way to make this heim.Fits Tube Size: 1 1/4" OD.x .120" Wall
This product is fulfilled by seller
2 Link 5/8" Adjustable Rod End Heim Joint Kit
Rod End：
Thread Size:5/8"-18
Ball Bore: 0.625"
Ball Width: 0.75"
Centerline Length: 2.625"
Thread Length: 1.625"
Load Capacity: 17,955 lbs
5/8 Bung：
Thread Size: 5/8"-18
Fits Tube Size: 1 1/4" OD.x .120" Wall
Fit for High Misalignment Spacer（SN10-87）:5/8"-1/2"(but package not including)
Jam Nut：
Thread:5/8"-18
Width: 0.938"
Height: 0.387"
Carbon Steel, Silver Zinc Plated
Rod End：
Thread Size:5/8"-18
Ball Bore: 0.625"
Ball Width: 0.75"
Centerline Length: 2.625"
Thread Length: 1.625"
Load Capacity: 17,955 lbs
5/8 Bung：
Thread Size: 5/8"-18
Fits Tube Size: 1 1/4" OD.x .120" Wall
Fit for High Misalignment Spacer（SN10-87）:5/8"-1/2"(but package not including)
Jam Nut：
Thread:5/8"-18
Width: 0.938"
Height: 0.387"
Carbon Steel, Silver Zinc Plated
| Brand Name | NOVINO |
|---|---|
| Part Number | HJ-004 |
