20T Hydraulic Jack + CP-180 Manual Hydraulic Hand Pump Multi Section Jack,Manual The Industries Such as Automotive Repair,Power,Chemicals,Steel,Bridges,and Machinery
- 【hydraulic jack】The stable structure, thick material, and premium hydraulic device endow the product with a load-bearing capacity of up to 44092.45 lbs, allowing you to handle heavy-lifting tasks with peace of mind
- 【Build to Last】High-class steel with chrome plated and plastic spraying processes make this product impact-resistant, corrosion-resistant, not easy to rust and deform, and can ensure long-term use.
- 【Wide Adaptability】The hydraulic jack can be used in any direction and is suitable for operation in most kinds of narrow spaces. With the 3-way diverter valve (not included), it can also work with multiple jacks at the same time.
- 【Thoughtful Design】The 13.4-inch-long hydraulic pump handle is ergonomic and comfortable to hold, so you won't feel fatigued even after a long time of use.
- 【Practical Tool】With its excellent performance and robustness, this product will help you to lift heavy objects easily, which is highly practical and saves you labor.
Application
It is widely used in the industries such as automotive repair, power, chemicals, steel, bridges, and machinery. It can be used for lifting and supporting heavy objects.
How to Operate
① Connect the quick connector.
② Tighten the knob of the manual pump clockwise.
③ Press the handle up and down.
④ Stop the work with the stroke in place (see the stop ring on the spindle).
⑤ Loosen the knob of the manual pump counterclockwise.
Specification
Color: Yellow
Style: Modern
Material: Steel
Process: Chrome Plated, Plastic Spraying
Load-bearing Capacity: 20T/44092.45lbs
Stroke: 12 mm/0.47in
Contraction Height: 56 mm/2.2in
Oil Pipe Length: 1m/3.28ft
Handle Length: 34cm/13.4in
Jack Size: 108*88*57mm/4.3*3.5*2.24in
Manual Pump Body Size(L*H): 33*11cm/13*4.3in
Packaging Size: 37.5*22.5*16.5cm/14.76*8.86*6.5in
Gross Weight: 7.6kg/16.76lbs
Net Weight: 7.22kg/15.92lbs
Package Included
1* Hydraulic Jack
1* Manual Hydraulic Pump
Notes
1.Please note that the load-bearing surface needs to be hard and flat.
2.Offsetting the load is strictly prohibited.
3.Please stop immediately when you see the stop line.
4.Please do not lift more than the maximum load capacity (44092.45 lbs) of the jack.
5.Please allow the slight color difference caused by the shooting light and 1-3 cm error due to manual measurement, and make sure you do not mind before ordering.
| Brand Name | FiueStur |
|---|---|
| Part Number | Manual Hydraulic Hand Pump |
| Load Capacity | 44092.45 |
| Maximum Lifting Height Decimal Value | 2.200000 |
| Maximum Lifting Height Unit | Inches |
