Ndarepoo Mini HD 1080P&30HZ SDI Fiber Extender Video Converter Broadcast Level SDI Video Optical Transceiver Up to 20km Over Single-Mode Single Fiber
- The SDI Fiber converter facilitates HD-SDI with an ?-??????? ????? ?????????, boasting a resolution up to ?????&????, with an Automatic reclocking range of ???????/? - ?.??????/?
- Tailored for the ????????????? ??????, ????? ??? ?????????? ??????, ?? (???? ???????), ????????? ??? ?? ????????, and more
- Operates in single mode up to ?? ??, with a ???????????? multi-mode option for the HD-SDI to fiber optic converter
- The dimensions of the HD SDI optical terminal stand at a mere ?×?.?×?.? ??????, showcasing a compact design that's a breeze to carry. Crafted from ???????? ?????, it's lightweight and resilient to falls
- It's crucial to note that this is ??? ? ??-??????????? ?????????. A transition to HDMI will necessitate an SDI to HDMI converter
Overview:
The HD-SDI Video supported by the SDI Fiber converter includes 8-channel embedded audio and offers resolutions up to 1080P at 30Hz, with automatic recloaking from 270Mbit/s to 1.48Gbit/s. With a propagation distance of up to 20 km for single mode and customizable options for multi-mode, this converter boasts a compact form factor, measuring only 3 by 1.1 by 0.7 inches.Its light weight yet durable aluminum alloy construction makes it resistant to falls. In addition, it ensures uncompressed transmission without delays or losses and is hot-pluggable and EMI/RFI resistant. The high compatibility of this device allows for automatic source and display device matching, and it also features automatic cable equalization to maintain signal integrity. It is directly compatible with HD-SDI camera systems and supports long-distance transmission of at least 20 km.
Features:
1.High adaptability, with an auto-matching feature for source and display device
2.Automatic cable equalization to preserve signal integrity
3.Uncompressed transmission, zero delay, zero losses
4.Hot-Pluggable, with robust EMI/RFI Resistance
5.Exceptional optic dynamic range and adjustment-free
6.Long-haul transmission capability extending at least 20 km
7.Seamlessly compatible with HD-SDI camera systems
Specifications:
Formats:1.5 Gbps, 270 Mbps (auto matically selected based on input)
Power:Type-C 5V
Power Consumption:2W (Max.)
Dimensions (LxWxH):77 x 28 x 18mm
Weight: 100g
Operating Temperature:-10℃~60℃
Packages:
1*SDI-IN Transmitter
1*SDI-OUT Receiver
2*Type-C 5V Power Adapter
2*SFP Module
1*Mini HD SDI Optical Terminal User’s Manual
| Brand Name | Ndarepoo |
|---|---|
| Part Number | 00001 |
| Input Voltage Unit | Volts |
| Input Voltage | 5.000000 |
