RTL SDR Receiver 100KHz To 1766MHz Full Band RTL2832U R820T2 0.5 PPM TCXO USB Software Defined Radio
$52.35
- [RTL SDR Receiver] This RTL SDR receiver covers 100KHz to 1766MHz, supporting AM, FM (NFM, WFM), CW, DSB, LSB, USB demodulation. Ideal for listening to medium , short , FM, aviation bands, and more. (Added features: CTCSS, DCS, frequency scanner, automatic scanning, etc.)
- [RTL2832U and R820T2 Chipset] Utilizes RTL2832U and R820T2 chipset for improved sensitivity compared to R820T, with better performance around 1.5 GHz. Fully compatible with old R820T software. Operating frequency 100KHz to 1766MHz, covering all amateur bands.
- [0.5 PPM TCXO] Features precise tuning and minimal temperature drift, covering all HF amateur bands, VHF, and UHF frequencies from 24 to 1766MHz, with up to 3.2M sampling rate (~2.8MHz stable). Receiver modes include AM, NFM, FM, DSB, USB, LSB, and CW.
- [Direct Sampling] Supports shortwave Q branch direct sampling (depending on SDR software used), with 8 bit ADC providing approximately 50 dB dynamic range, 50 ohm input impedance, and independent antenna inputs for shortwave and VHF.
- [USB Computer Connection] Mini USB powered, receives low, medium, high frequencies (0 to 30MHz). HF band antenna must be connected to input port, while reception requires compatible antennas like long wire, random wire, dipole, etc., for optimal performance.
This product is fulfilled by seller
Specification:
Item Type: RTL SDR Receiver
Material: Aluminum Alloy, PCB
Features:
1. RTL2832U+R820T2 chipset
2. 100KHz to 1766MHz operating frequency
3. Covers all amateur bands
4. 0.5 PPM temperature compensated oscillator (TCXO)
5. Covers 24-1766MHz VHF and UHF bands
6. Receiver Modes: AM, NFM, FM, DSB, USB, LSB, and CW
7. Direct sampling of and shortwave Q branch
8. 8 bit ADC providing approximately 50dB dynamic range
9. 50 ohm input impedance
10. Independent antenna inputs for shortwave and VHF
11. USB computer connection (mini USB) powered by general USB, directly sampling RTL SDR technical specifications
How to Use:
Directly sample RTL SDR technology specifications, assemble to use.
PackageList:
1 x RTL SDR Receiver
1 x Cable
2 x Antenna
Item Type: RTL SDR Receiver
Material: Aluminum Alloy, PCB
Features:
1. RTL2832U+R820T2 chipset
2. 100KHz to 1766MHz operating frequency
3. Covers all amateur bands
4. 0.5 PPM temperature compensated oscillator (TCXO)
5. Covers 24-1766MHz VHF and UHF bands
6. Receiver Modes: AM, NFM, FM, DSB, USB, LSB, and CW
7. Direct sampling of and shortwave Q branch
8. 8 bit ADC providing approximately 50dB dynamic range
9. 50 ohm input impedance
10. Independent antenna inputs for shortwave and VHF
11. USB computer connection (mini USB) powered by general USB, directly sampling RTL SDR technical specifications
How to Use:
Directly sample RTL SDR technology specifications, assemble to use.
PackageList:
1 x RTL SDR Receiver
1 x Cable
2 x Antenna
| Brand Name | Srliya |
|---|---|
| Part Number | Srliya82wgrfcxzo |
| Includes Remote? | No |
| FCC ID | No |
