PF10000260894
In stock
IDC-64 DIN Rail Mounted Interface Module 2x32 Pins 0.1" Male Header Breakout Board, Terminal Block, Connector.
$31.98
- Modular Design: This interface module features a 2x32 pin
- 1" male header breakout for easy connection to various electronic components.
- Convenient Mounting: With a DIN rail mount, the module can be securely installed on standard DIN rails for a tidy and organized setup.
- Robust Construction: Constructed with high-quality materials, this terminal block connector ensures reliable performance and durability.
- Versatile Application: Suitable for a wide range of industrial, automation, and control system applications that require secure wire terminations.
This product is fulfilled by seller
IDC-64 DIN Rail Mounted Interface Module. IDC pin pitch 2.54mm/0.1" male header connector.Pitch 5.0mm/0.197" screw terminal block. Din rail mountable - for width 35 / 32 / 15mm rails. Din mount case can be taken apart for panel mount use. FR-4 fiber glass PCB, dual copper layers. PCB Dimensions: 72.5 x180mm(W x L). External dimensions: 87 x 182x 54mm(W x L x H). 100% new, never used. Rated voltage: 60V. Rated current: 1A / per pin. Operating Temperature: -20ºC to 50ºC Terminal block specifications:Wire range - 24-12AWG.Strip length - 5mm.Screws - M3,steel,Zinc plating color.Pin header and Cage - Brass.
| Brand Name | SZ-WEEL LONG |
|---|---|
| Part Number | IDC-64M-A3 |
| Lower Temperature Rating | -20.000000 |
| Gauge Decimal Value | -0.010000 |
| Operating Voltage Unit | Volts |
| Operating Voltage | 60.000000 |
