PF10000260146
In stock
WIDIA H104Z12304 TOP Drill Deep-Hole Drill, 0.4844" Cutting Diameter, 132° Cutting Angle, RH Cut, 30XD, 0.5118" Shank, Carbide, TiAlN Coating
$1,157.99
- 132° TDS point geometry for low thrust and excellent centering
- 30° helix with optimized flute profile reduces risk of chip jam
- Four-margin lands improves hole alignment and straightness
- Highly polished surfaces reduce friction in the ship flute improving evacuation
- WU20PD grade for steel and cast iron
This product is fulfilled by seller
| Brand Name | WIDIA |
|---|---|
| Part Number | 3899675 |
| Manufacturer Series Number | TDD108 |
| Maximum Cut Depth Unit | Inches |
| Maximum Cut Depth String Value | 14.888500000000001 |
| Cutting Angle String Unit | Degrees |
| Cutting Angle String | 132.0 |
| Shank Diameter Unit | Inches |
| Shank Diameter String Value | 0.51180000000000003 |
| Cutting Diameter Unit | Inches |
| Cutting Diameter String Value | 0.4844 |
| Cutting Length Unit | Inches |
| Cutting Length String Value | 15.9528 |
| Item Dimensions Fraction Length Unit | Inches |
| Item Dimensions Fraction Length | 18.55 |
