Eapmic Hydraulic Hand Pump with 10T Short Jack,Single-Acting Mini Jack Ram with CP-180 Hydraulic Hand Pump Hand Operated Hydraulic Pump for Hydraulic Applications
- ★【Durable Material】-- The item is made of steel, which is relatively strong and stable.It is also not easy to damage or rust under proper use and is very durable.
- ★【Large Reservoir Capacity】-- It has a reservoir capacity of 350cc, so you can use it easily without frequent refilling.
- ★【User-friendly】--The manual hydraulic pump has a long ergonomic operating handle for a smoother, more comfortable grip during use. Its thickened insulation feature also provides non-slip hand protection for long-term use.
- ★【Strong Power】-- The maximum working pressure of the hydraulic pump can reach 70Mpa, which is more powerful than other similar machines and more convenient to use.And its jack has a tonnage of 10T/22046lbs, providing you with stronger power.It not only has a smooth surface, but also has good sealing and no oil leakage.
- ★【Wide Use】-- It can be used with hydraulic punches, hydraulic cutting machines, hydraulic cylinders, hydraulic tongs, etc. to perform various operations, such as lifting, bending, straightening, shearing, riveting, assembly, disassembly, etc.
Features
Steel Wire Joint Sheath: Its joint is equipped with steel wire protection, which can effectively avoid damage caused by excessive bending of the joint oil pipe so that it can be used for a long time.
Thickened Plunger: The thickened design of the plunger increases its wear resistance, which can effectively increase the service life of the manual hydraulic pump.
High-pressure Oil Pipe: It adopts a high-pressure oil pipe (1m/ 3.3ft) and attaches a quick joint（ZG3/8''）, which makes it convenient and fast for you to use.
How to Use
1. Connect the jack to the quick coupler of the hydraulic pump.
2. Turn the pressure relief valve on the hydraulic pump clockwise.
3. Press the handle up and down.
4. Stop working when the stroke is in place.
5. Turn the relief valve counterclockwise.
Specifications
Name: Manual Hydraulic Pump
Model: BSY-10 + CP-180
Color: Orange
Material: Steel
Surface Treatment: Plastic Spraying
Condition: Brand New
Type: Manual
Oil Reserves: 350CC
Maximum Pressure: 70Mpa（700kg/ cm²）
Low-Pressure Speed: 2L/ s (0.44Gal/ s)
High-Pressure Speed: 0.2L/ s (0.044Gal/ s)
Tubing Connector: ZG3/8''
Jack Tonnage: 10T/ 22046lbs
Jack Spindle Diameter: 38mm/ 1.5in
Inner Diameter of Jack Cylinder: 45mm/ 1.77in
Jack Stroke: 11mm/ 0.43in
Jack Extension Height: 64mm/ 2.52in
Pump Body Length: 33cm/ 13in
Pump Body Height: 11cm/ 4.3in
Handle Length: 34cm/ 13.4in
Tube Length: 1m/ 3.3ft
Lifting Jack Size: 8.3*6.5*5cm/ 3.3*2.6*2in
Package Size: 37.5*22.5*16cm/ 14.76*8.86*6.3in
Net Weight: 5kg/ 11.02lbs
Gross Weight: 5.8kg/ 12.79lbs
Package Included
1* Manual Hydraulic Pump
1* Lifting Jack
1* 1m Hose
1* Hand
| Brand Name | Eapmic |
|---|---|
| Part Number | YDDBDB5452DHDB |
