Supco SHP450250 High Pressure Control Switch 450-250 PSI
$23.99
- Supco SHP450250 High Pressure Switch
- High pressure SPST open on pressure rise
- Temperatures: Ambient 20°F to 176°F (-30°C to 80°C). Fluid 60°F to 250°F (-50°C to 120°C)
- Related Voltage: 50/60 Hz, 24/120/240 Volts (6 RLA, 36 LRA)
- Life at rated load: 100,000 cycles
This product is fulfilled by seller
Supco SHP450250 High Pressure Switch
High pressure SPST open on pressure rise
Temperatures: Ambient 20°F to 176°F (-30°C to 80°C). Fluid 60°F to 250°F (-50°C to 120°C)
Related Voltage: 50/60 Hz, 24/120/240 Volts (6 RLA, 36 LRA)
Life at rated load: 100,000 cycles
1/4" SAE female flare fitting with valve core depressor
Snap acting stainless steel hermetically sealed sensor (SHP, SLP, and SFC)
Small size and lightweight for direct mounting
Excellent set point repeatability/stability
Pressure range: 0 to 650 PSI
Burst pressure: 5000 PSI
Tolerance: ±15 PSI
Close PSI: 250
Open PSI: 450
High pressure SPST open on pressure rise
Temperatures: Ambient 20°F to 176°F (-30°C to 80°C). Fluid 60°F to 250°F (-50°C to 120°C)
Related Voltage: 50/60 Hz, 24/120/240 Volts (6 RLA, 36 LRA)
Life at rated load: 100,000 cycles
1/4" SAE female flare fitting with valve core depressor
Snap acting stainless steel hermetically sealed sensor (SHP, SLP, and SFC)
Small size and lightweight for direct mounting
Excellent set point repeatability/stability
Pressure range: 0 to 650 PSI
Burst pressure: 5000 PSI
Tolerance: ±15 PSI
Close PSI: 250
Open PSI: 450
| Brand Name | HVAC Parts |
|---|---|
| Part Number | HP051121-04 |
| Number of Positions | 3 |
| Wattage | 696.000000 |
| Wattage Unit | Watts |
| Lower Temperature Rating | 20.000000 |
| Operating Voltage Unit | Volts |
| Operating Voltage | 240.000000 |
| Control Method | Touch |
