Game Boy Color: USB-C Charging Mod PRO 3 in 1 (Charger, Power supply & Audio Amp) - GILTESA
$26.00
- The Game Boy Color USB-C Charging Kit PRO is a new circuit designed specifically for the Nintendo Game Boy Color. This all-in-one circuit includes not only the charging controller but also a boost converter and audio amplifier.
This product is fulfilled by seller
DESCRIPTION The Game Boy Color USB-C Charging Kit PRO is a new circuit designed specifically for the Nintendo Game Boy Color. This all-in-one circuit includes not only the charging controller but also a boost converter and audio amplifier. The modern IPS displays with backlighting require more power than the original display, and flash cards used to load tons of games can quickly drain the battery. To truly enjoy the games, it is recommended to use a rechargeable battery instead of AA batteries. However, simply using a rechargeable battery is not sufficient. The increased power consumption puts a strain on the original electronics, potentially causing noise in the speaker or headphones. The typical solution is to add a charging circuit for the battery and a power converter to replace the old, inefficient one included in the GBC. Some individuals also add an audio amplifier to enhance the sound quality of the speaker. All these modifications make the GBC function optimally. However, installing them requires numerous cables and may be challenging for individuals without sufficient knowledge. FEATURES - Exact shape for Game Boy Color. - Li-Ion battery charger by USB-C with overvoltage and undervoltage protection. - DC to DC converter of 5V output. (The board doesn’t support original screen, only IPS screens supported) - Safe charge and play. - Audio amplifier for the speaker. - Integrated LED indicators on the main board, next to the USB for charging battery (red) and full battery (green). It can be disabled by the jumper SJ1. - External LED indicators board for playing (white), charging battery (red) and full battery (green). Optional installation. INCLUDED - 1 frame panel which includes the two boards: Main board & Light board. - 1 Battery cable. - 1 Cable of 2 wires for connecting the light board. - 1 Cable of 1 wire for connecting the board to the sound pad. - 1 Light diffuser pipe (in clear white color from v3.1) REQUIRED (NOT INCLUDED) - Li-ion battery (for example 123048, perfect for an IPS V3 laminated screen shell) - New speaker 8Ω 1W (optional but recommended to avoid noise, for example this one) - New capacitors (optional but recommended to avoid noise) - Cutting tool (optional but recommended) - Tri-wing sand phillips screwdriver - Cutting plier - Cutter - Tweezers - Tin soldering iron - Tin - Flux - Isopropyl alcohol
| Brand Name | Generic |
|---|---|
| Part Number | 00001 |
| Language | English |
