PF10000252875
In stock
SMAJAYU Tractor GPS, Auto Steer System 2.5cm Accuracy by RTK Base 10cm Precision by PPP Without RTK, AB Line in Straight Curve A+ Pivot U-Turn Mode for Planting Spraying Harvesting
$4,475.00
- 2.5cm Accuracy: Correction sources by RTK Base R26 or CORS give the JY305 autosteering system an accuracy of 2.5 cm. Please purchase the JY305+R26 RTK base bundle if you do not have CORS. Otherwise, it operates in PPP mode with an accuracy of 10 cm and above. There is no need for additional networks subscriptions or charges when using R26 RTK BASE or PPP
- Necessary Parts: 1)Included extra and built-in gyroscope: Single or double gyro mode both work with the JY305 gps system for tractor 2) Included type A spline with 36 teeth and a diameter of 21.3-21.7 mm, which is compatible for New Holland and John Deere. Free additional spline from SMAJAYU is available to fit kinds of brand tractor
- Software and Support: 1)multiple language:English,Spanish,French...Multiple constellations and frequencies. Farm measurement and farm management supported. The field size,speed can be seen on the display. Import A-B line supported 2) Installation manual,video Training and remote diagnosis are supported
- Package Inclusions: 10-inch waterproof tablet with a high-precision GNSS board, a high-torque auto steering motor with an integrated controller,a high-precision GNSS GPS receiver, a extra gyroscope and additional cables and tools. Weight:20kg/set, Size: 67.5*48.5*26.8cm/set
- Working Instructions and Uses: On a farm, this tractor auto steering system can steering on its own which reduces labor investment, increases farmer productivity and makes farming more intelligent for sowing, cultivating, trenching, ridging, spraying, transplanting, consolidating land, harvesting, and other tasks. It can be used with a wide range of tractors, harvesting equipment, rice transplanters, plant protection equipment, and other agricultural implement
- What is it: Auto steering system includes a 10'' water proof tablet integrated with a high-precision GNSS Board, a high touque auto steering motor with built-in controller, an angle sensor, high precision GNSS GPS receiver built in gyroscope and wireless module and accessories cables and tools
- How to work:This tractor Auto steering system can automatically driveless on farm. Login CORS account or connect with RTK base to get correction service so that it get 2.5cm stable precision farming. Otherwise use PPP mode to get 10cm accuracy. 20minutes Installation and accuracy debugging then Start creating farms, plots and AB lines
- Why use: Improve farming accuracy and effiencey. It integrates the advantages of convenient installation, large torque, high precision, remote diagnosis, and quick debugging, online remote support. This system management makes farming intelligent, enhances farmer productivity and saves labor cost
- Where to use: It can be widely used for sowing, cultivating, trenching, ridging,spraying pesticide,transplanting,land consolidation, harvesting and other work scenaries. It is suitable for various applications of JOHN-DEERE tractors, harvesting machines, plant protection Elect machinery, rice transplanters,and other agricultural models
- Key Features: Supports multiple constellations & frequencies:GPS L1, L2 GLONASS L1, L2 BeiDou B1,B2 ,B3.Remote support, and OTA software update，Multiple languages supported, Map-based navigation,Task Controller functionality via Setting A-B for straight/Curve or A+ line, pivot
This product is fulfilled by seller
SMAJAYU's JY305 Auto-Steering System is a cutting-edge automatic steering solution designed to elevate tractor navigation. It harnesses the power of high-torque motor control for precise steering wheel operation. The auto-steer system offers hassle-free installation, eliminating the need for extensive debugging. It simplifies the setup process, saving valuable time. SMAJAYU's auto-steer solution achieves an astounding accuracy of ±2.5cm through Real-Time Kinematic (RTK) technology. This level of precision ensures that tractors follow precise paths with minimal deviation, resulting in optimal crop planting and harvesting. The system is compatible with various satellite constellations and frequencies, including GPS L1, L2; GLONASS L1, L2; BeiDou B1, B2; GALILEO E1, E5b; QZSS L1, L2; and SBAS L1. This extensive satellite support ensures robust and reliable performance across diverse regions and countries. Correction mode: Solution1: Autosteer system JY305+Mobile RTK base, Solution2: JY305+CORS account network base station Solution 3: JY305 work with PPP mode no need RTK base. Tractor Autosteering empower farmers to attain unmatched precision, ultimately elevating productivity and efficiency in their fields. It provides an automated solution to ensure tractors follow precise paths, minimizing overlaps and gaps. This not only saves time and resources but also optimizes planting, harvesting, and other tasks. Auto-steer systems relieve them of the constant need to steer, reducing fatigue and enhancing their overall well-being avoiding long hours in the field taking a toll on tractor operators. This results in safer and more efficient farming practices while improving the quality of work.
| Brand Name | SMAJAYU |
|---|---|
| Part Number | JY305 |
| Maximum Range Unit | Meters |
| Maximum Range | 0.000000 |
| Impedance Unit | Ohm |
| Impedance | 0.000000 |
| Item Height Unit | Inches |
| Item Height base to top | 7.000000 |
| Item Length Unit | Inches |
| Item Length Longer Edge | 11.000000 |
| Item Width Unit | Inches |
| Item Width Shorter Edge | 1.650000 |
| FCC ID | 2AT4H-T100 |
