MENGQI-CONTROL 1 Door Access Control Board System 600lbs Electromagnetic Lock Infrared No Touch Exit Button RFID Keypad Reader 110~240V Power Supply Box USB Enroll Reader,Phone APP remotely Open Door
$509.99
- Control 1 door, get in door by swiping card/key fob, inputting PIN code or using card + PIN, and get out door by infrared button. Can store/download/check entry records and generate report by professional management software. Exit button can perfect install on US electrical box.
- Control of memory up to 20,000 user / up to 100,000 logs. Auto open/close at any pre-set time during any day. Support "who" can enter which door at certain time, authorized access control.
- Card Type: EM-ID card .Response Speed: Less than 0.2 second.The magnetic lock is with 600lbs holding force.
- Have smart phone APP to open lock remotely.App operate system: iOS & Android.Desktop USB reader,read card number into software so that easy programming/register user. Detail video guide and wire diagram make all easily, you can DIY.
- Network communication via TCP/IP. Software Supportable Database: Access & SQL Server. Support Win7/Win8/Win10/Win11 both 32 & 64 bit ALL Windows system.
This product is fulfilled by seller
We provide video guide+Detail wire diagram, so you can easily setup System, also provide live support.
Package:
1 x 1 Door Access control Panel
1 x Magnetic Lock(600lbs force)
1 x Keypad Reader
1 x Power supply Box( 110-240V input,5A output,to power the system,also as cabinet for control board)
1 x RFID Enroll USB Reader
1 x Infrared Exit Button
50 x RFID Keychains
50 x RFID Cards
1 x CD for Software/User manual/Wire diagram/Video Guide
USB RFID Card Reader:
Desktop USB reader,read card number into software so that easy programming/register user
Support: EM4100/EM4001/TK4100 ID card
Dimension: 105x70x12mm
Power Supply Box:
Power：60W, Rated Current：5A
Input Voltage：110V-240V,Output Voltage：12VDC
Color of the box：black
Size of the box：279mm * 234mm * 67mm
Access-Control-Panel-Controller Feature:
Control 1 door,get in by swiping card and get out door by button
Door controlled : 1
Support 1 reader
Control of memory up to 20,000 user / up to 100,000 event buffers
Network communication via TCP/IP
Infrared Exit Button Specifications:
No touch / Touch free Exit Sensor(Diffused Detection)
Contact Rating: 3A/AC120V, DC30V
Input Voltage: DC12V
Operation temperature range: -20C-55C
Life: 500,000 Times
Dimension: 114mm x 70mm x 29mm
Weight: 85g
Magnetic Lock
Collinear Load Test 280kg/600pounds
MOV Provides Reverse Current Protection
Anti-Residual Magnetism Designed
High Strength Material,Anodized Aluminum Housing
Design without Mechanical Failure
Increase the holding Force,Dual Insulative Housing
125Khz 12V RFID Keypad Reader Features:
Can't work alone,need work with access control panel
Supports Card, PIN, Card + PIN
Reading range: 3~15 cm
Size: 86*86*18 mm
Package:
1 x 1 Door Access control Panel
1 x Magnetic Lock(600lbs force)
1 x Keypad Reader
1 x Power supply Box( 110-240V input,5A output,to power the system,also as cabinet for control board)
1 x RFID Enroll USB Reader
1 x Infrared Exit Button
50 x RFID Keychains
50 x RFID Cards
1 x CD for Software/User manual/Wire diagram/Video Guide
USB RFID Card Reader:
Desktop USB reader,read card number into software so that easy programming/register user
Support: EM4100/EM4001/TK4100 ID card
Dimension: 105x70x12mm
Power Supply Box:
Power：60W, Rated Current：5A
Input Voltage：110V-240V,Output Voltage：12VDC
Color of the box：black
Size of the box：279mm * 234mm * 67mm
Access-Control-Panel-Controller Feature:
Control 1 door,get in by swiping card and get out door by button
Door controlled : 1
Support 1 reader
Control of memory up to 20,000 user / up to 100,000 event buffers
Network communication via TCP/IP
Infrared Exit Button Specifications:
No touch / Touch free Exit Sensor(Diffused Detection)
Contact Rating: 3A/AC120V, DC30V
Input Voltage: DC12V
Operation temperature range: -20C-55C
Life: 500,000 Times
Dimension: 114mm x 70mm x 29mm
Weight: 85g
Magnetic Lock
Collinear Load Test 280kg/600pounds
MOV Provides Reverse Current Protection
Anti-Residual Magnetism Designed
High Strength Material,Anodized Aluminum Housing
Design without Mechanical Failure
Increase the holding Force,Dual Insulative Housing
125Khz 12V RFID Keypad Reader Features:
Can't work alone,need work with access control panel
Supports Card, PIN, Card + PIN
Reading range: 3~15 cm
Size: 86*86*18 mm
| Brand Name | MENGQI-CONTROL |
|---|---|
| Part Number | 1door-k-infrared-usb em |
| FCC ID | 2A5R9-SIB |
