MENGQI-CONTROL Keypad Reader North American Heavy Duty Strike Lock Access Control System for Gym Center Sports Club Fitness Cente or Home/Office Entrance Security Kits Phone APP Remotely Open Door

We provide video guide+Detail wire diagram, so you can easily setup System, also provide live support.


Package:
1 x 1 Door Wiegand Access control Panel
1 x Power supply Box( 110-240V input, 5A output, to power the whole system, also as cabinet for above control board )
1pc RFID Enroll USB Reader
1 x RFID Keypad Reader
1 x ANSI Strike Lock(1000kg Force, Fail Secure, Keep locked in case of power failure, also can adjust to Fail Safe mode)
50 x RFID Keychains
50 x RFID Cards
1 x Push to Exit Button
1 x CD for Software/User manual/Wire diagram/Video Guide

RFID Card USB Reader Features:
Desktop USB reader,read card number into software so that easy programming/register user
Support: EM4100/EM4001/TK4100 ID card
Dimension: 105x70x12mm
Size:125K EM4100

Power Supply Box:
Power：60W, Rated Current：5A
Input Voltage：110V-240V,Output Voltage：12VDC
Color of the box：black
Size of the box：279mm * 234mm * 67mm

1 Door Access-Control-Panel Feature:
Control 1 door,get in by swiping card and get out door by button
Door controlled : 1
Support 2 readers
Control of memory up to 20,000 user / up to 100,000 event buffers
Network communication via TCP/IP

ANSI Strike lock Features:
Fail secure, NO mode(Locked when power is removed)
Lock Size : 123Lx43Wx42H(mm) / 4.84Lx1.69Wx1.65H(inch)
Testing to 1000000 cycles
High-Temperature Painted,Duable and Beatiful Artical
Strike Structure : Stainless Steel
Holding Force : 1000kg
Voltage:DC12V
Suitable For : Wooden Door,Metal Door,PVC Door
Face plate Housing : Painted Steel
Lock tongue : Surface by coating nickel

RFID Keypad Reader Features:
Frequency: 125Khz
Card Type: EM-ID Card
Response Speed: Less than 0.2 second
Proximity Time Distance: Less than 0.5 seconds
Reading range: 3-15cm
Communication distance: Less than 100m
