Tinsley 4721 High Resistance Single Decade Box 5000V DC
- Overall Range: 1kΩ to 1TΩ in 10 steps with open circuit on eleventh position.
- Accuracy Stated at 20° C±1°C 10 to 50%RH
- Earthing: Metal earth terminal on switch panel. Connections: Plug-in shielded plugs with 1 metre shielded cable (2 off High and Low)
- Please allow 4 - 5 weeks lead time for this new product to arrive. Comes with a one year warranty from the manufacturer.
The Tinsley Model 4721 decade box is designed for the checking and calibration of insulation testers at voltages of up to 5000V DC.
The total range covered is from 1 kΩ to 1TeraΩ using specially selected resistors and a high quality switch mounted on an easy to read panel.
This resistance box is housed in a strong aluminium case with lid and carrying handle to provide an ideal solution to on-site and laboratory calibration of high resistance insulation testers.
The instrument can be supplied complete with a calibration certificate provided by our own in-house calibration laboratory.
Switch Volts Accuracy Temp Coefficient
1kΩ 20V ±0.1% 15ppm/deg. C.
10kΩ 75V ±0.1% 15ppm/deg. C.
100kΩ 200V ±0.1% 15ppm/deg. C.
1MΩ 500V ±0.1% 25ppm/deg. C.
10MΩ 2000V ±0.1% 50ppm/deg. C.
100MΩ 3000V ±1% 100ppm/deg. C.
1GΩ 5000V ±1% 100ppm/deg. C.
10GΩ 5000V ±1% 100ppm/deg. C.
100GΩ 5000V ±2% 2000ppm/deg. C.
1TΩ 5000V ±2% 2000ppm/deg. C
| Brand Name | Tinsley |
|---|---|
| Part Number | 4721 |
