PF10000246720
In stock
RadioLink RC4GS V3 2.4G 4CH RC Transmitter and Receiver R6FG Gyro Inside Pistol Grip Remote Controller for RC Car Boat Tank Buggy
$64.99
- 1) 【Built in Gyro】: Built-in gyro can keep the vehicle in a straight line, and Gyro sensitivity can be adjusted by the transmitter's VR switch, which fits for drifting car and on-road cars. switch, which fits for drifting car and on-road cars.
- 2) 【Excellent Anti-interference】: With pseudo random FHSS algorithm, which makes RC4GS V3 with excellent anti-interference ability, control range up to 1300 feet (400 meters).
- 3) 【Adapts to Most of Types Vehicles】: with 30 models storage and each model can be set up alarming and named separately, assigning 1 of 10 receivers to work separately on menu ID SEED.
- 4) 【Dual Programmable Mix Control】: Any two channels can be mixed control and each channel can be customized, it also support one switch to ON/OFF mix control. Dual rate function support one switch to change different servo travel.
- 5) 【Powerful Function】: EPA, ABS, fail-safe, dual-rate, timer, cruise control, FPV head tracking, low power alarming, subsidiary ID (control multiple receivers separately),etc. CH3-CH5 can be customized to VR and tact switch.
This product is fulfilled by seller
RC4GS V3 General Information1) 5 channels, 30 models memory storage, a key switch to change mixes control, dual-rate and cruise control, with timer setting for training and racing, DSC port is optional for simulator, TBS crossfire.2) RC4GS V3 can be works with: R7FG/R6FG/R6F/R4FGM/R8F/R8EF. 3) Note: please calibrate ESC (electronic speed control) before first use RC4GS V3 with your car.Specification: Size: 174.8*116.4*224.2mm(6.88*4.58*8.83") Weight: 319g(11.28oz) Channel: 5 channels Model Memory: 30 ID seed: 10 Antenna Length: 106mm(4.17") Control Range: 400 meters Operating Current: 80-120mA Operating Voltage: 4.8-16.8V,(6pcs of AA batteries or a 2S-4S LiPo battery),Battery not included. RF Power: <20dbm Frequency: 2.4Ghz ISM Band(2400MHz--2483.5MHz) Modulation Mode: GFSK LCD Screen: 128*64 Resolution, LCD Backlight Channel resolution: 4096 with regular jitter of 0.5us Spread Spectrum: FHSS 67 Channels Pseudo Random Frequency Sequence Hopping Low Voltage Alarm: Yes. When less than 7.2V or customized on 2-4S battery. (Customizable for each model) Adaptable Models: Car(Incl.Crawlers/Tanks/Caterpillars etc.)/Boat/Robot Compatible Receiver: R6FG(Standard), R7FG,R6F, R8EF, R8F, R4FGM,R4F Battery Tray Dimension: 89*59*25mm (3.5*2.32*0.98")Receiver R6FG(Standard Pack) Receiver packed with RC4GS V3 is R6FG, 2.4GHz 6channels,gyro integrated and high voltage servo supported. Size: 35*20*13mm (1.38*0.79*0.51") Weight: 6g (0.21 oz) Channel: 6 channels Antenna Length: 205mm(8.07") Operating Current: 30mA Operating Voltage: 3-12VBinding 1. Put the transmitter and the receiver close to each other (about 50 centimeters) and power both on. 2. Switch on the transmitter and the led on R6FG will start flashing slowly. 3. There is a black binding button(ID SET) on the side of receiver. Press the button for more than 1 second and release, the led will flash quickly, meaning binding process is ongoing. 4. When the led stops flashing and is always on, binding is complete and there will be a signal tower shown on top of the LCD screen of the transmitter. If not succeed, the led will keep flashing slowly to notify, repeat the above steps.R6FG has two working modes：normal working mode and gyro working mode. 1. Normal Working Mode Green LED, gyro will NOT be working. 2. Gyro Function Working Mode Both GREEN and RED LED on.Package contents: 1x Radiolink RC4GS V3 transmitter 1x R6FG Gyro Receiver 1X English manual
| Brand Name | Radiolink |
|---|---|
| Part Number | DTUS_RC4GS |
| Target Gender | Unisex |
| Manufacturer Minimum Age (MONTHS) | 180.000000 |
| Number of Batteries | 0 |
| FCC ID | U2BRL039RC6GS |
