ANMBEST DB15 Female Solderless Breakout Connector with 5Ft 26AWG Replacement Cable, Plastic Shell RS232 D-SUB Serial to 15-Pin Port Terminal Female Adapter Connector Breakout Board
$27.99
- DURABLE: Pure copper plated joints, fine solder joints, resistance to plug, and good contact to ensure high-quality, durability and a long life.
- Stable Transmission: This DB15 Solderless Breakout Connector adopts 26AWG double-layer shielded cable and copper crimp terminals, which has stable signal transmission and good shielding effect.
- DB15 line sequence color comparison table: 1. Black; 2. Brown; 3. Red; 4. Red and white; 5. Orange; 6. Yellow; 7. Yellow and white; 8. Green; 9. Green and white; 10. Blue; 11. Purple; 12. Gray; 13. White; 14. Pink; 15. Light green.
- The cable length is 1.5m/5Ft, the compact and simple design is easy to carry and place, easy to use and resistant to bending and stretching.
- WIDELY APPLICATIONS: It can connect all kinds of rs232/rs485 and other communication protocols devices. Such as computer and tax control machine, digital camera, PLC, PDA, MODEM, set-top box, barcode machine, industrial instrumentation and other equipment for communication.
This product is fulfilled by seller
The DB15 solderless breakout connector is a connector that can be attached to a DB15 interface without the need for soldering. It provides easy access to the individual pins, making it easier to connect wires or other components. It also comes with a 5-foot-long replacement cable that uses 26-gauge wire.
Technical Specifications:
Name: DB15 solderless module with cable
Plug type: female
Connector material: pure copper plated joint
Terminal Material: red copper
Housing material: plastic shell
Cable Length: 1.5m/5Ft
Cable Specification: 26AWG
Thickness: 16mm/0.63″
Application: tax control machine, digital camera, PLC, PDA, MODEM, set-top box, barcode machine, industrial instrumentation, etc.
Size: 54 mm×43.5 mm×16 mm/ 2.13″×1.71″×0.63″
Package includes:
1 x DB15 Female Solderless Connectors with 1.5m Bare Wire End Cable
Technical Specifications:
Name: DB15 solderless module with cable
Plug type: female
Connector material: pure copper plated joint
Terminal Material: red copper
Housing material: plastic shell
Cable Length: 1.5m/5Ft
Cable Specification: 26AWG
Thickness: 16mm/0.63″
Application: tax control machine, digital camera, PLC, PDA, MODEM, set-top box, barcode machine, industrial instrumentation, etc.
Size: 54 mm×43.5 mm×16 mm/ 2.13″×1.71″×0.63″
Package includes:
1 x DB15 Female Solderless Connectors with 1.5m Bare Wire End Cable
| Brand Name | ANMBEST |
|---|---|
| Part Number | 00001 |
| Gauge Decimal Value | 26.000000 |
