RAINBOW ELECTRONICS Capillary Thermostat TS-050SR 32-122F

- Model. : TS-050SR 32-122F
- Part No. : P-TS01350
- Temperature range. : 32℉~122℉ (0°C ~ 50°C)
- Accuracy : ± 3.6℉ (±2°C)
- Differencial : 3.6℉±1.8℉ (2± 1°C)
- Max. ambient temp. for body : 248℉ (120°C)
- Max. temperature for bulb : 140℉ (60°C)
- Electric rating : 20A/250VAC
- Switch circuit : Single Pole Double Throw (SPDT)
- Mounting bracket :.M4 fixed bracket (28mm from center to center)
- Direction of terminal : Straight
- Net weight : 96g
- Bulb dimension : Stainless, Ø5.8*127mm (± 5mm)
- Capillary length : Stainless, 1000mm ± 50mm
- Type of Knob : R type Knob
- Bending radius for cap. Tube : min.5mm
- Packing content : 1*capillary thermostat , 1*manual. (br> - Packing dimension(individual carton) : 60 * 50 * 170 mm
- Gross weight(including ind. package) : 123g
- Certificate : UL, TUV, CE, california pro.65, RoHS compliant

◀Caution & Notice ▶

1. Please mind this instructions before installing a thermostat to your equipment and contact the supplier for any question or doubt.
2. Use it in allowed electric rating for your safety.
3. Carefulness is required to handle bulb and capillary to prevent breaking.
4. Do not bend the capillary less than 5mm radius
5. Do not bend the terminals by force.
6. A damaged bulb can make fail the desired temperature.
7. Thermostat body should be installed away from heating source. The higher ambient temperature can affect its normal function.
8. Sensing bulb should be installed in or close to heating source. Otherwise it can be out of the allowed tolerance.
9. Terminals deformation is not allowed for safety.
10. Refund or replacement is not accepted for voluntary fixing or modifying.
11. Applying the supplied parts with the thermostat.
