Tire Bead Breaker, 10000PSI Air Hydraulic Bead Breaker with Air Hydraulic Foot Pump and Air Hose, 40-150PSI Pressure Range, Heavy Duty Tire Bead Breaker Kit for Tractor Truck Car
- 【Hydraulic Bead Breaker】: Max Pressure 10000psi (700bar); Pressure Range: 40-150psi (2.8 to 10.3Bar). The hydraulic bead breaker can deliver strong force in seconds to break beads under hydraulic action.
- 【Hydraulic Foot Pump】The pump adopts the foot-actuated design for easy control and operation, saving your time and effort with strong power. 3 pedal functions, apply pressure, hold pressure, release pressure.
- 【Heavy Duty Construction】The bead breaker is constructed of reinforced steel brackets. The foot pump is made of aviation aluminum. The high-pressure oil pipe adopted double protection of embedded steel wires and thickened outer layer, durable for a long service life.
- 【Safe Operation】Our tire bead tool kit can perform greatly on the tires by loosening tire bead from the rim with leverage. The foot pump is built-in safety overload pump saver ensures work safty; With release lock plate, so the operator can release and remove foot as release/return takes effect.
- 【Wide Use】The bead breaker kit works on any 1, 2 and most 3 piece 2-5-10 hole budd and all tubeless truck tires rims, including some new style wheels. Can be used on truck, farm, tractor, garder, combine, and skidder tires with wheel still on.
Product Description:
Type: Hydraulic Air Foot Pump
Model: 1/2 gal Hydraulic Air Foot Pump
Output oil hole: 3/8NPTF connection
Intake: 1/4NPT connection
Placement on Vehicle: Body
Features: Maximum adjustable pressure 10000psi 700 kg/square cm
Power Source: Foot
Dimensions: 315*175*210mm
Rated pressure: ≤70
Flow rate: 0.75-0.95/Lmin
Hydraulic oil: No. 32
Drive mode: pneumatic
Available oil: 2.3L
Installation Instructions: Not included
Specification list:
1. 1/4NPT air inlet.
2. 3/8 NPT oil output, safely builds to 10,000 pounds and has a built in safety overload pump saver.
3. Oil flow / delivery: 0.75-0.95L/min
4. Reservoir capacity: 2.3L
5. Release lock plate so operator can release and remove foot as release / return takes effect.
6. 3 pedal functions, apply pressure, hold Pressure, release pressure.
Type: Hydraulic Bead Breaker
Working range: up to 5inch
Pressure Range: 40-150psi (2.8 to 10.3Bar)
Max Pressure: 10,000psi (700bar)
Bead Separation Force: 13.8 tons
Effective length of shoveling tire: 2.34inch
Material: Cast Iron
Installation Instructions: Not included
Features:
Hydraulic bead breaker delivers 10,000 lbs. of pure mus-cle to break beads smoothly.
Works on any 1, 2 and most 3 piece 2-5-10 hole budd and all tubeless truck tires rims, including some new style wheels.
Breaks beads in seconds using 10,000 lbs of force.
No screws, bolts, or attachment.
Not for use in 5 piece rims.
Uses any 10,000 PSI hydraulic pump.
Self-retracting.
Working range up to 5inch.
Can be used on truck, farm, tractor, combine, and skidder tires with wheel still on.
Package includes:
1 * Hydraulic Bead Breaker
1 * Air Hydraulic Jack Pump Rotary Lift
1 * Air Hose
| Brand Name | HAOREBAIYU |
|---|---|
| Part Number | CSFW598 |
| Is the item dishwasher safe? | No |
