Square D by Schneider Electric 9013FHG52J59X Air-Compressor Pressure Switch, 175 psi Set Off, 40 psi Fixed Differential, 1/4" NPSF Internal, 2-Way Release Valve_x000D_

This Square D Pumptrol 9013FHG52J59X air-compressor pressure switch controls an electrically driven air compressor in a power circuit when the adjustable threshold upon falling is reached and is set to turn off at 175 psi. The switch has a 1/4" NPSF internal fluid connection and is suitable for use with a higher-horsepower motor with 2 hp or greater. The non-adjustable differential is 40 psi, and the adjustable cut-out range is 100-200 psi. The switch is diaphragm actuated and has a fixed differential. The threshold, or setting point, upon rising adjusts with a screw nut. The switch has screw terminal electrical connections, and two 2-pole NC contacts open on rising pressure. The enclosure is National Electrical Manufacturers Association (NEMA) Type 1 and Ingress Protection (IP) 20 rated. The switch is Underwriters Laboratories (UL) Listed and Canadian Standards Organization (CSA) certified. This switch includes a 2-way pressure release valve. Square D Pumptrol pressure switches are manufactured by Schneider Electric.
