Solder Fume Extractor – Fume Extraction for soldering, jewelry making, and crafting

ESD-Safe Solution for a Variety of Applications: The Solder Fume Extractor captures and filters smoke and particulate emitted during soldering applications. This benchtop unit provides an effective, quiet, and economical solution for many soldering operations that require a small, energy efficient footprint. This unit offers an ESD safe workspace allowing operators to safely work on electronics without having to worry about electrostatic discharge.

High Quality Filtration Options: This ductless unit creates a recirculating airflow pattern with high-quality filtration including HEPA (up to 99.97% efficiency on particles 0.3 microns and larger) or ASHRAE (up to 95% efficiency on particles 0.5 microns and larger). Both filters are created from all flame-retardant material.

The Solder Fume Extractor offers an effective, quiet, and economical solution for many benchtop soldering operations which require fume extraction.



Technical Specifications:
Air Volume: Up to 70 CFM (Depends on Filter Media)
Electrical: 115/1/60, Approx. 0.46 Amps
Cord: 8’ grounded power cord with NEMA 5-15P Plug
Sound Level: 66 DBA at 3’
Filtration Options: HEPA (99.97% efficiency on particles 0.3 microns and larger) –OR– ASHRAE (95% efficiency on particles 0.5 microns and larger)
Filter Part Numbers: HEPA - SS-100-HF , ASHRAE - SS-100-95A
