Sorekarain 24 Plates Wort Chiller Cooler Heat Exchanger SUS 304 Stainless Steel Home Brew Beer Wine Making

Material:SUS 304 Stainless Steel (Food Grade)
WeldIing Material:99.9% Copper
Application:Home Brew Wort Chiller,Famliy Hot Water supply
Thread of Port A1?A2:1/2" BSPT Male
Thread of Port B1?B2:1" BSPT Male
Plates Number:24
Denension:195x85x75mm
Heat Transfer Area/plate: 0.028 m2(0.30 ft2)
Thickness of One Plate:0.25-0.35mm
Max Flowrate:12 m3/H
The Maximum Pressure: 1.6Mpa(228 PSI)
Refrigeration Capacity: 5 KW(1465 BTU/hour)
Working Temperature:-160 ? to + 185 ?
Using Way for hot Wort:Port A1:Hot Wort,Port A2:Cold Wort
Port B1:Cold Water,Port B2:Hot Water
The flowrate of Cold Water higher the Better.
Using Way for Famliy hot water supply:Port A1:Cold Water,Port A2:Hot Water
Port B1:Central heating In;,Port B2:Central heating Out
Each bid For 1 PC!
We also have other relevant products.Please feel free to contact us!
