Generic 32 Plates Heat Exchanger Beer Wort Chiller Cooler 304 Stainless Steel for Home Brewing Beer
$0.00
- 32 Plates Heat Exchanger Beer Wort Chiller Cooler 304 Stainless Steel For Home Brewing Beer
This product is fulfilled by seller
Material:SUS 304 Stainless Steel ( Grade)
WeldIing Material:99.9% Copper
Application:Home Brew Wort Chiller,Famliy Hot Water supply
Thread of Port A1.A2:1/2'' BSPT Male
Thread of Port B1.B2:1'' BSPT Male
Plates Number:32
Denension:195x85x105mm
Heat Transfer Area/plate: 0.028 m2(0.30 ft2)
Thickness of One Plate:0.25-0.35mm
Max Flowrate:12 m3/H
The um Pressure: 1.6Mpa(228 PSI)
Refrigeration Capacity: 6.5 KW(1905 BTU/hour)
Working Temperature:-160 ℃ to + 185 ℃
Using Way for hot Wort:Port A1:Hot Wort,Port A1:Cold Wort
Port B1:Cold Water,Port A2:Hot Water
The flowrate of Cold Water higher the Better.
Using Way for Famliy hot water supply:Port A1:Cold Water,Port A2:Hot Water
Port B1:Central heating In;,Port B1:Central heating Out
Each bid For 1 PC!
| Brand Name | Generic |
|---|---|
| Part Number | ZYIMDJSH_16665 |
