PF10000225054
In stock
Dayton Water Pump Pressure Switch; Range: 10 to 100 psi, Port Type: (1) Port, 1/4" FNPT
$0.00
This product is fulfilled by seller
This diaphragm-actuated water pump pressure switch features a 10 to 100 psi differential pressure range.
Item: Pressure Switch
Pressure Switch Application: Water Pump
Manual Switch Action: Auto/Off/Reset
Pressure Switch Port Type: (1) Port, 1/4" FNPT
Pressure Switch Factory On/Off Setting: 30/50 psi
Pressure Switch Unloader: No
Pressure Switch Differential: 15 to 50 psi
Pressure Switch Range: 10 to 100 psi
Pressure Switch Electrical Contact Form: DPST
Pressure Switch Action: Standard
NEMA Rating: 1
Series: Dayton
HP @ 1 Phase - 120V: 1-1/2
HP @ 1 Phase - 240V: 2
Temp. Range: -22 Degrees to 250 Degrees F
Standards: UL Listed, CSA Certified
Special Features: Low Pressure Cut-Off
AC Contact Rating: 20/17A @ 120/240V
Item: Pressure Switch
Pressure Switch Application: Water Pump
Manual Switch Action: Auto/Off/Reset
Pressure Switch Port Type: (1) Port, 1/4" FNPT
Pressure Switch Factory On/Off Setting: 30/50 psi
Pressure Switch Unloader: No
Pressure Switch Differential: 15 to 50 psi
Pressure Switch Range: 10 to 100 psi
Pressure Switch Electrical Contact Form: DPST
Pressure Switch Action: Standard
NEMA Rating: 1
Series: Dayton
HP @ 1 Phase - 120V: 1-1/2
HP @ 1 Phase - 240V: 2
Temp. Range: -22 Degrees to 250 Degrees F
Standards: UL Listed, CSA Certified
Special Features: Low Pressure Cut-Off
AC Contact Rating: 20/17A @ 120/240V
| Brand Name | CAI - DAYTON |
|---|---|
| Part Number | 12T085 |
| Current Rating Unit | Amps |
| Current Rating | 20.000000 |
| Operating Voltage Unit | Volts |
| Operating Voltage | 120.000000 |
