24 Plate Heat Exchanger Beer Wort Chiller Cooler SUS 304 Stainless Steel for Homebrew Cooling(3l4 Inch BSPT)
$101.84
- Smooth Thread makes a easy, quick, flexible hookup.
- Compact and lightweight design & quick and easy intallation
- Using this plate chiller can reduce oxidation in your homebrew heat exchange.
- It's perfect to use in the lab, for beer brewing, or for any application that requires the exchange of heat between two fluids.
- Provides the level of durability in a compact lightweight unit, this water heat exchanger is ideal for domestic water heating, floor heating, snow melting, wort chille, solar heating, zone heating systems, residential and light commercial HVAC hydronic systems.
This product is fulfilled by seller
Material:SUS 304 Stainless Steel
WeldIing Material:99.9% Copper
Application:Home Brew Wort Chiller,Famliy Hot Water supply
Thread of Port A1,A2:1/2" BSPT Male
Thread of Port B1,B2:1" BSPT Male Or 3/4"BSPT
Plates Number:24
Denension:195x85x75mm
Heat Transfer Area/plate:0.028 m2(0.30 ft2)
Thickness of One Plate:0.25-0.35mm
Max Flowrate:12 m3/H
The Maximum Pressure: 1.6Mpa(228 PSI)
Refrigeration Capacity:5 KW(1465 BTU/hour)
Working Temperature:-160 to + 185
Using Way for hot Wort:Port A1:Hot Wort,Port A2:Cold Wort
Port B1:Cold Water,Port B2:Hot Water
The flowrate of Cold Water higher the Better.
Using Way for Famliy hot water supply:Port A1:Cold Water,Port A2:Hot Water
Port B1:Central heating In;,Port B2:Central heating Out
WeldIing Material:99.9% Copper
Application:Home Brew Wort Chiller,Famliy Hot Water supply
Thread of Port A1,A2:1/2" BSPT Male
Thread of Port B1,B2:1" BSPT Male Or 3/4"BSPT
Plates Number:24
Denension:195x85x75mm
Heat Transfer Area/plate:0.028 m2(0.30 ft2)
Thickness of One Plate:0.25-0.35mm
Max Flowrate:12 m3/H
The Maximum Pressure: 1.6Mpa(228 PSI)
Refrigeration Capacity:5 KW(1465 BTU/hour)
Working Temperature:-160 to + 185
Using Way for hot Wort:Port A1:Hot Wort,Port A2:Cold Wort
Port B1:Cold Water,Port B2:Hot Water
The flowrate of Cold Water higher the Better.
Using Way for Famliy hot water supply:Port A1:Cold Water,Port A2:Hot Water
Port B1:Central heating In;,Port B2:Central heating Out
| Brand Name | Bolisila |
|---|---|
| Part Number | Bolisila |
