Srliya Antenna Tuner Mini Automatic for Radio Equipment 1.8~55MHz 0.96IN with Housing ATU‑100
$84.13
- STABLE AND PRACTICAL: Adopt good quality metal shell, possess stable and performance, practical, easy to operate and use, long service life
- FOR RADIO STATIONS: Antenna tuner automatically tunes without any control wires, suitable for most radio stations
- 0.96IN DISPLAY WITH HOUSING: Mini shortwave automatic antenna tuner come with Type C charging port, 0.96in OLED display
- EXCELLENT CONFIGURATION: C channel capacitors adopt good quality 1000V high voltage SMD capacitors, and advanced PIC chips. UHF Connector
- ALUMINUM ALLOY: Made of good quality aluminum material, light weight, possess good strength and good
This product is fulfilled by seller
1. STABLE AND PRACTICAL: Adopt good quality metal shell, possess stable and performance, practical, easy to operate and use, long service life
2. FOR RADIO STATIONS: Antenna tuner automatically tunes without any control wires, suitable for most radio stations
3. 0.96IN DISPLAY WITH HOUSING: Mini shortwave automatic antenna tuner come with Type C charging port, 0.96in OLED display
4. EXCELLENT CONFIGURATION: C channel capacitors adopt good quality 1000V high voltage SMD capacitors, and advanced PIC chips. UHF Connector
5. ALUMINUM ALLOY: Made of good quality aluminum material, light weight, possess good strength and good
Spec:
Item Type: Antenna Tuner
Material: Aluminum alloy
Model: ATU-100
Display: 0.96in OLED
Operating Frequency: 1.8-55 MHz
Battery Model: 3.6V lithium battery 1350MAH
USB Charging Current: 1A
Maximum Operating Power: 100 watts
Maximum Possible Measured Power: 150 watts
1 Watt: Necessary to start setting the minimum power
Minimum Possible Measured Power: 0.1 watts
Measurement Steps With Power Up To 10W: 0.1W
When Robust Measurement Steps STI 10 Watts: 1 watt
Power Measurement Accuracy: 10%
Specified Maximum Inductance: 8.53uH capacitance
Minimum Installation Step Size of Inductor: 0.05?H
Maximum Mounting Capacity: 1869 pF Capacitor
Minimum Installation Step: 10
How to Use:
ATU Antenna Tuner Instructions for Use:
1. Connect Radio, ATU Antenna Tuner, Antenna
2. When using for the first time, please set the output power of the radio or power amplifier between 20?30W, warning that high power tuning may easily damage the antenna tuner.
3. Set radio mode, use FM mode
4. Select the antenna frequency band to use, use 20?30W power in FM mode, press radio PPT, observe the ATU antenna tuner PWR and SWR
5. Use of ATU button TUNE: Short
2. FOR RADIO STATIONS: Antenna tuner automatically tunes without any control wires, suitable for most radio stations
3. 0.96IN DISPLAY WITH HOUSING: Mini shortwave automatic antenna tuner come with Type C charging port, 0.96in OLED display
4. EXCELLENT CONFIGURATION: C channel capacitors adopt good quality 1000V high voltage SMD capacitors, and advanced PIC chips. UHF Connector
5. ALUMINUM ALLOY: Made of good quality aluminum material, light weight, possess good strength and good
Spec:
Item Type: Antenna Tuner
Material: Aluminum alloy
Model: ATU-100
Display: 0.96in OLED
Operating Frequency: 1.8-55 MHz
Battery Model: 3.6V lithium battery 1350MAH
USB Charging Current: 1A
Maximum Operating Power: 100 watts
Maximum Possible Measured Power: 150 watts
1 Watt: Necessary to start setting the minimum power
Minimum Possible Measured Power: 0.1 watts
Measurement Steps With Power Up To 10W: 0.1W
When Robust Measurement Steps STI 10 Watts: 1 watt
Power Measurement Accuracy: 10%
Specified Maximum Inductance: 8.53uH capacitance
Minimum Installation Step Size of Inductor: 0.05?H
Maximum Mounting Capacity: 1869 pF Capacitor
Minimum Installation Step: 10
How to Use:
ATU Antenna Tuner Instructions for Use:
1. Connect Radio, ATU Antenna Tuner, Antenna
2. When using for the first time, please set the output power of the radio or power amplifier between 20?30W, warning that high power tuning may easily damage the antenna tuner.
3. Set radio mode, use FM mode
4. Select the antenna frequency band to use, use 20?30W power in FM mode, press radio PPT, observe the ATU antenna tuner PWR and SWR
5. Use of ATU button TUNE: Short
