AD32R V1.2 Resistor Decade Box,1Ω to 11MΩ,1% Accuracy, 8 Decades Resistance Range.
$82.00
- APPLICATION: It is the most commonly used instrument in all laboratories and is suitable for electrical measurement and other experimental purposes in schools, factories, and research institutions.
- ABOUT THE DEVICE:The AD32R decade resistance box is used as an adjustable resistance value in the power supply circuit, with a low zero resistance.
- PRODUCT INFORMATION: 8 decade resistance range from 0.1Ω to 11,111,111Ω ,over 11MΩ, in0.1Ω steps; With 1% accuracy, it is ideal for prototyping, education, and professional calibration of test equipment.
- DIMENSIONAL WEIGHT: 6.8 x 3.9 x 2.0；Net weight: 0.57 lb
- EASY TOU SE:32 slide switches organized in a clean 4 x 8 grid；each switch displays a visible white dot when in the ON position; two binding posts for easy versatile connection with banana plugs, bare wires, spade lugs, or alligator clips
This product is fulfilled by seller
Firstly, based on the resistance value you need, if it is less than 10 ohms, you can toggle the switch at the bottom of the panel to select the<10 Ω range,which will reduce the internal resistance error. Conversely, if it is greater than10 ohms, you must select the>10 ohms range.Slide switches allow for easy addition and subtraction of internal Resistancevalues. Switches that are in the ON position are clearly marked by a white dot below it to easily distinguish it from those that are OFF.
| Brand Name | Alignimals |
|---|---|
| Part Number | AD32R |
