12VDC Continuous Duty Solenoid Relay 3-Terminal | Fits for Trombetta Maxon Waltco Delco Littelfuse, Max 200A Inrush | Replaces 9341215010, 97240-X, 70091714, ATU120, 1114240, 1114241, 1114538, 24106

Be the first to review this product

$0.00

Compatible with Trombetta 934-1215-010, 9341215010, 934-1215-010-16, 934121501016 | Maxon 223741, 97240-X | Waltco 70091714 | Anthony Atu120 | Delco 1114240, 1114241, 1114538 | Littelfuse 24106 |
Voltage: 12VDC | Resistance: 14Ω | Inrush current: 200A | Continuous Working Current recommend: 100A |
Body Shell Plating: Zinc-Plating | Mounting Bracket: Flat, Open Slots | Mounting holes: 5/16 x 19/32, 2-13/64 on centers |
Contact Form: SPNO (Single Pole Normally Open) | Contact Termination: 5/16”-24 UNF Thread | Coil Termination: #10-32 UNF Thread |
Fits: Military Vehicles, Hydraulic Control Units, Golf Carts, Trucks, Marine, Winch And Factory Machines
WARNING: This is a Normally Open solenoid, Max 10 min continuous duty @ 150Amp, NEED BREAK otherwise it will be overheated.
Suggestion: If it is the energizing circuit which is typically 16/18 AWG, suggest a 5 AMP fuse; If 10 AWG wire suggests 30 AMP auto circuit breaker; If high output alternator, suggest an 8 AWG wire with a 50 AMP auto circuit breaker.
Warranty: For any reason, if you are not satisfied with your purchase, contact us directly. We offer 1-year warranty, 100% satisfaction guarantee.

This product is fulfilled by seller

Skip to the beginning of the images gallery

Details

More Information

Reviews

Questions

the starter solenoid relay is a critical component in a vehicle's starting system, responsible for engaging the starter motor by allowing high-current flow from the battery. It plays a crucial role in the vehicle's ignition process and ensures smooth and reliable engine starting. If you experience starting problems with your vehicle, the starter solenoid relay is one of the components that should be checked for potential issues.

More Information
Brand Name	LLNSEAUTO
Part Number	S012-1114240
Current Rating Unit	Amps
Current Rating	200.000000
Maximum Switching Current Unit	Amps
Maximum Switching Current	5.000000
Maximum Switching Voltage Unit	Volts
Maximum Switching Voltage	12.000000
Coil Resistance	14.000000
Coil Voltage	12.000000
Coil Voltage Unit	Volts
Contact Current Rating Unit	Amps
Contact Current Rating	200.000000
Minimum Switching Voltage	12.000000
