100 Plates SUS 304 Heat Exchanger Beer Wort Chiller Cooler Homerbrew

Material:SUS 304 Stainless Steel ( Grade)
WeldIing Material:99.9% Copper
Application:Home Brew Wort Chiller,Famliy Hot Water supply
Thread of Port A1.A2:1/2'' BSPPT Male
Thread of Port B1.B2:1'' BSPPT Male
Plates Number:100
Denension:195x85x310mm
Heat Transfer Area/plate: 0.028 m2(0.30 ft2)
Thickness of One Plate:0.25-0.35mm
Max Flowrate:12 m3/H
The Maximum Pressure: 1.6Mpa(228 PSI)
Refrigeration Capacity: 20 KW(5860 BTU/hour)
Working Temperature:-160 ℃ to + 185 ℃
Using Way for hot Wort:Port A1:Hot Wort,Port A2:Cold Wort
Port B1:Cold Water,Port B2:Hot Water
The flowrate of Cold Water higher the Better.
Using Way for Famliy hot water supply:Port A1:Cold Water,Port A2:Hot Water
Port B1:Central heating In;,Port B2:Central heating Out
Each bid For 1 PC!
We also have other relevant products.Please feel free to contact us!
