Commercial Hat Embroidery Machine with 15 Needles 20" x13" Embroidery Area, 10" Touch Screen, Fully Automatic Embroidery Machine for Mass Production
- Versatile Needle Configuration: Offers 1-15 needles with the ability to switch between soft and hard fabrics, providing high efficiency and versatility.
- Advanced Control System: Features a DAHAO A15 electric control system with a 10-inch high-definition color LED touch screen, supporting design track preview and 14 languages, including Chinese, English, Turkish, and Spanish.
- Multiple Connectivity Options: Supports WiFi wireless network and 3 USB ports, enabling seamless pattern transfer and connectivity.
- Efficient and User-Friendly: Capable of automatic start, 200 color changes, and a maximum speed of 1000 RPM. Includes features like a DC 36V power switch, laser positioning, and restart capability after power failure.
- Adaptable and Portable: Designed for use with various types of fabrics and products, with a movable caster base for easy relocation and adjustable brackets to meet different embroidery needs.
Technical Specifications
1. 10 inch Touch Screen Computer
2. Maximum Number of Patterns Saved in Memory: 800
3. Memory Capacity: 100 million stitches
4. Screen Resolution Ratio: 1280*8003
5. Network Port Speed:100 Mbps
6. Supported Method for Data 7.Exchange: USB disk, netwofk 5.
8. Control Pecision: Minimum controllable stitch intervalis 0.6.
9. Stitch Range: 0.1mm~12.7mm
10. System supports Chinese, English, Turkish, Spanish, and so on total 14 kinds languages
Touch screen
It adopts high-brightness liquid crystal display and touch screen.
Three buttons make perations more efficient.
Needle Wire Rack
1. RLASTIC TUBE Keep the thread walk well to Avoid windy and shaking.
2. Connect each interface in an orderly manner without knotting
3. High quality material
4. Never rust material
5. Auto thread trimmer and auto color change.
6. The number of needles canbe increased as required.
| Brand Name | Wlvos |
|---|---|
| Part Number | WL1883 |
| Automatic Shutoff | Yes |
| Is Electric | Yes |
| Control Method | Touch |
| Item Depth Unit | Inches |
| Item Depth Front to Back | 29.500000 |
| Item Height Unit | Inches |
| Height Top to Bottom | 67.300000 |
| Item Width Unit | Inches |
| Item Width Side to Side | 27.200000 |
| Manufacture Year | 2024 |
