4Pcs LCD1602 Keypad Shield Module 4.5-5.5V LCD 1602 Display Expansion Shield Board Blue Backlight
$17.99
- This is a basic 16 character by 2 line black-on-green display, dot matrix LCD module which is used for displaying letters, numbers and symbols etc.
- 1602 LCD keypad shield 1602 LCD expansion shield board4.5-5.5V, 4 bit LCD library,V3 design, pins out for easy connecting
- Based on HD44780 LCD parallel interface chip set and adopts standard 16-pin interface.
- Uses 4 Bit LCD Library, has a contrast adjustment knob, backlight selection switch, but also with four directional buttons, a selection button And a reset button.
- 1602 LCD expansion board in the true sense of the circuit will be simplified, directly to the board inserted your controller can be, Interface code is freely available.
This product is fulfilled by seller
This is a basic 16 character by 2 line black-on-green display
Utilizes the extremely common HD44780 parallel interface chip set
Interface code is freely available
Display capacity:16x2characters
Current:2.0mA
Operating Voltage: 5V
5 Push buttons to supply a custom menu control panel
RST button for resetting program
Integrate a potentiometer for adjusting the backlight
Utilizes the extremely common HD44780 parallel interface chip set
Interface code is freely available
Display capacity:16x2characters
Current:2.0mA
Operating Voltage: 5V
5 Push buttons to supply a custom menu control panel
RST button for resetting program
Integrate a potentiometer for adjusting the backlight
Pin used:
D4-D7 -> LCD Data transmission
D8 -> Register Select
D9 -> Enable pin
D10 -> Backlight control
APC&BT pin header for connecting wireless devices, directly
Package Included:
4 x 1602 LCD Keypad shield
