Awxlumv 40mm Heatsink Kit 40x40x20mm with Thermal Conductive Adhesive Tape, Aluminum Heat Sink Cooler for Cooling 3D Printer Stepper Motor Driver NEMA 17 TEC1-12706 Peltier Plate Module GPU Router
$10.99
- 1. 40mm anodized aluminum heatsink
- 2. Pre-applied blue 3M8810 thermal conductive adhesive tape backing
- 3. These heat sinks perfect fit for cooling of 3D Printer Motor, NEMA 17, TEC1-12706 Thermoelectric Peltier Cooler etc. Also for GPU backplate/ LED light/ Wi-Fi Routers/ Power Supplies and so on.
- 4. Dimension: 1.57 x 1.57 x 0.79inch / 40x40x20mm (L*W*H)
- 5. Weight: 0.94 oz / 26.9 gr per pc
This product is fulfilled by seller
Heatsink kit 40mm x 40mm x 20mm extruded aluminum heatsink kit is specially designed for Cooling 3D Printer, NEMA 17, TEC1-12706 Thermoelectric Peltier Modules.
This set of heatsink height is 20mm. This kit is made from 6063-T5 aluminum alloy with high thermal conductivity 201 W/m.K, structure stability and light weight.
The heatsink extrusion is in vertical and horizontal grooves; that is greatly increases the heat dissipation function.
The surface of extruded aluminum is anodized in black.
This kit of heatsink comes with 40x40mm pre-applied thermal conductive double sided adhesive tape, for easy installation and optimum heat conductivity.
40mm aluminum heatsink kit
- Material: Extruded Aluminum 6063-T5
- Color: Black
- Coating: Anodized
- Weight: 0.95oz /27 gr per piece
- Mounting Style: SMD/SMT
- Fin Style: Vertical
- Number of fins: 11x6 p>
- Tape Thermal Conductivity: 0.8 W/m-K
- Package Includes: 4 pieces 40mm heatsink
| Brand Name | Awxlumv |
|---|---|
| Part Number | 40 x 40 x 20 mm |
| Cooler Heatsink Compatibility | 3D Printer Stepper Motor, Nema 17, Peltier Thermoelectric Module TEC1-12706, Peltier Thermoelectric Module TEC1-12703, Peltier Thermoelectric Module TEC1-127103D Printer Stepper Motor, Nema 17, Peltier Thermoelectric Module TEC1-12706, Peltier Thermoelectric Module TEC1-12703, Peltier Thermoelectric Module TEC1-12710, PC chipset, Robotic Projects, LED Modules... |
| Item Height Unit | Inches |
| Item Height base to top | 0.790000 |
| Item Length Unit | Inches |
| Item Length Longer Edge | 1.570000 |
| Item Width Unit | Inches |
| Item Width Shorter Edge | 1.570000 |
