Ndarepoo Mini 3G-SDI Fiber Extender 1080P&60HZ, SDI Over Fiber Optical Converter, Include SFP Module, Long Transmission Up to 20 km with RS485, Tally, Loop Output
- Hassle-Free Transmission: Supports a 3G-SDI input, reverse Tally indicator signal transmission. The transmitter features a loop output, while the receiver supports dual outputs.
- Wireless Signal Transmission: Fully digital, lossless transmission with no compression or delay. Synchronous audio and video transmission, supporting HDTV 1080P, 1080I, 720P, and a maximum resolution of 1920x1080@60Hz.
- Worry-Free Operation: Excellent compatibility—no need to select specific signal sources or equipment. Features adaptive technology for plug-and-play functionality, without the need for manual adjustments.
- Easy Signal Monitoring: The 2-color BNC design allows for quick identification of input and output signals. LED status indicators offer real-time monitoring of power, optical path, video, and other parameters.
- Durable and Reliable Quality: Housed in an aluminum alloy shell, making it ideal for industrial environments. Operating temperature range: -20°C to 70°C.
Overview:
The Ndarepoo 3G SDI Fiber Extender includes a transmitter and receiver, transmitting SDI and reverse Tally indicator signals over single-core, single-mode fiber, with a range up to 20km. It's widely used in multimedia recording, HD display, news centers, and more, making it an ideal choice for high-performance video transmission.
Features:
Lossless Transmission: Uncompressed, no delay, and no signal loss.
Hot-Pluggable & EMI/RFI Resistant: Easy connection with electromagnetic interference resistance.
High Compatibility: Auto-matches source and display devices.
Signal Integrity: Automatic cable equalization for rates up to 3.2 Gb/s (Belden 1694A).
Long Distance: Transmission distance of up to 20km.
No Adjustment Needed: Wide optical dynamic range, no manual tuning required.
Embedded Audio: 8 audio channels per signal.
Flexible Wavelengths: 1470~1610nm CWDM wavelength options.
Specification:
Automatic reclocking 270Mbit/s - 1.48Gbit/s - 3Gbit/s
Handle all Pathological patterns, fully digital non-compression broadcast level transmission;
LED Status Indication to monitor the working conditions;
Supported Resolution: 625/25PAL;525/29.97NTSC;525/23.98NTSC; 720p50; 720p59.94; 1080P23.98/24/30/50/60; 1080i 23/24/30/50/59.94;
Power adaptor: DC 5~25V
MTBF: ≥100000 hours
Box size(L*W*H): 80*40*20 (mm)
Net weight: 500g
Packages:
1 * ZP-M3G-1V-T TX (Transmitter, To Video Source)
1 * ZP-M3G-1V-R RX (Receiver, To TV/Display)
2 * Power Adapter
2 * SFP Module
1 * Mini SDI Fiber extender User’s Manual
